News

Credo and EFFECT Photonics Announce Collaboration on High-Performance, Ultralow Power Coherent DSP Solutions
Industry Leaders Join Forces to Meet the Next Generation Needs of Service Providers, 5G Telecom…
Industry Leaders Join Forces to Meet the Next Generation Needs of Service Providers, 5G Telecom and Fixed Access Operators
EINDHOVEN, The Netherlands and SAN JOSE, Calif.—Credo (NASDAQ:CRDO) and EFFECT Photonics today announced plans to collaborate on the development of coherent Digital Signal Processor (DSP) merchant ICs, featuring industry-leading power dissipation and performance. The DSPs are expected to deliver the capacity and reach needed to meet the explosive demands for connectivity and bandwidth and enable cost-effective network upgrades over existing physical fiber infrastructure. These merchant silicon offerings have the added benefit of giving customers the flexibility to choose from a variety of transceiver suppliers.
The two companies will work together to develop new coherent DSP products featuring EFFECT Photonics’ coherent DSP technology and Forward Error Correction (FEC), combined with Credo’s high-speed SerDes, I/Os, Analog to Digital Converters (ADCs), and Digital to Analog Converters (DACs). Credo will manufacture and manage the sales and supply channels of the co-developed merchant ICs, and provide complete design services and customer support.
The first products will target 100G ZR and 100G ZR+ applications. The products will work within the popular QSFP28 optical module’s ultralow 5W power envelope and extend network reach well beyond 80km to support advanced application requirements. These products will target new buildouts and the imminent 10G upgrade cycle to 100G for service providers, 5G telecom and fixed-access operators.
Alan Weckel, Founder and Technology Analyst at 650 Group stated, “Merchant solutions will help drive down the cost, and with the installed base of 10G ports in excess of 13M ports, there is a significant installed base that needs to upgrade to 100G to support new applications and traffic patterns, plus potential new market opportunities that coherent DSPs can open up in service provider, cloud, and enterprise edge networks.”
“Coherent technologies are gaining importance as they improve spectral efficiency and increase data throughput. Historically, coherent solutions have been mostly deployed for very long distances due to their high power and high cost,” said Scott Feller, Vice President of Marketing at Credo. “Our first collaboration with EFFECT Photonics will allow us to deliver capabilities that fit into the power envelopes of the most commonly used transceivers at a competitive price, providing our large volume customers with a refined solution that will seamlessly integrate into their existing access and edge infrastructure to address the dramatic bandwidth growth at the network edge.”
“Our field-proven coherent technology and Credo’s high-performance, power-efficient connectivity solutions and semiconductor manufacturing expertise provide a potent combination that we believe could truly revolutionize the network edge and access interconnect market,” said Harald Graber, Chief Commercial Officer at EFFECT Photonics. “The clear market need for this technology presents a truly exciting opportunity for both of our companies.”
The joint solutions will offer numerous benefits, including high performance, small size, excellent energy efficiency and cost-efficient production.
DSP Feature Set/Advantages:
- Optimized ZR and ZR+ solutions cover 40 to 500km links.
- Energy-efficiency with ultralow power consumption.
- Devices will be rated for both commercial and industrial temperature operating ranges.
- Compliant with industry standards.
- Credo’s high-speed data converters, SerDes and I/Os, are optimized for performance and energy efficiency.
- EFFECT Photonics’ best-in-class, field-proven coherent DSP and FEC technology (gained through the company’s acquisition agreement with Viasat).
- Credo will be the sole supplier of the merchant ICs, working with its foundry partners to provide dependable supply chain fulfilment with competitive lead times.
- Credo’s DSP expertise leverages its N-1 process technology advantage to deliver the most cost-effective coherent DSPs in the market.
About Credo
Our mission is to deliver high-speed solutions to break bandwidth barriers on every wired connection in the data infrastructure market. Credo is an innovator in providing secure, high-speed connectivity solutions that deliver improved power and cost efficiency as data rates and corresponding bandwidth requirements increase exponentially throughout the data infrastructure market. Our innovations ease system bandwidth bottlenecks while simultaneously improving on power, security and reliability. Our connectivity solutions are optimized for optical and electrical Ethernet applications, including the emerging 100G (or Gigabits per second), 200G, 400G and 800G port markets. Our products are based on our proprietary Serializer/Deserializer (SerDes) and Digital Signal Processor (DSP) technologies. Our product families include integrated circuits (ICs), Active Electrical Cables (AECs) and SerDes Chiplets. Our intellectual property (IP) solutions consist primarily of SerDes IP licensing.
For more information, please visit: https://www.credosemi.com. Follow Credo on LinkedIn and Twitter.
About EFFECT Photonics
Where Light Meets Digital – EFFECT Photonics is a highly vertically integrated, independent optical systems company addressing the need for high-performance, affordable optic solutions driven by the ever-increasing demand for bandwidth and faster data transfer capabilities. Using our field-proven digital signal processing and forward error correction technology and ultra-pure light sources, we offer compact form factors with seamless integration, cost efficiency, low power, and security of supply. By leveraging established microelectronics ecosystems, we aim to make our products affordable and available in high volumes to address the challenges in 5G and beyond, access-ready coherent solutions, and cloud and cloud edge services.
For more information, please visit: https://www.effectphotonics.com. Follow EFFECT Photonics on LinkedIn and Twitter.
# # #
Media Contacts:
Diane Vanasse
Credo
Diane.vanasse@credosemi.com
Colleen Cronin
EFFECT Photonics
colleencronin@effectphotonics.com

EFFECT Photonics Secures $40 Million in Additional Funding
Eindhoven, The Netherlands — EFFECT Photonics, a leading developer of highly integrated optical solutions, has…
Eindhoven, The Netherlands — EFFECT Photonics, a leading developer of highly integrated optical solutions, has secured an additional $40 million in funding from a group of investors led by Invest-NL and Innovation Industries, along with other existing investors.
The new investment enables the company to accelerate product development and fuel go-to-market initiatives, specifically those related to its integrated coherent optical product portfolio and solutions that meet the industry need for disaggregation of the key components for the growing needs of coherent optical interfaces.
“We’re thankful to Invest-NL, Innovation Industries, and our other existing investors for their continued support and confidence in EFFECT Photonics mission and products,” said Roberto Marcoccia, CEO, EFFECT Photonics. “This investment positions us well to advance our portfolio of integrated optic solutions that will reshape the future of communications and positively disrupt the status quo.”
Gert-Jan Vaessen, Fund Manager Deep Tech Fund at Invest-NL – “Invest-NL’s Deep Tech Fund is established to support companies with innovative, complex technologies focusing on future societal challenges. Our investment in EFFECT Photonics is within that goal. We are very happy to support our existing deep tech portfolio company EFFECT Photonics, together with the other shareholders, for further growth. Management is well-focused on future developments and has positioned EFFECT Photonics as a tier-one business partner.”
“Innovation Industries is excited to offer our continued support of EFFECT Photonics. We are impressed by the company’s plans for future growth and innovative product portfolio, which is forging new grounds in offering the lowest power per bit,” said Nard Sintenie, Partner, Innovation Industries.
###
About EFFECT PHOTONICS
Where Light Meets Digital – EFFECT Photonics is a highly vertically integrated, independent optical systems company addressing the need for high-performance, affordable optic solutions driven by the ever-increasing demand for bandwidth and faster data transfer capabilities. Using our field-proven digital signal processing and forward error correction technologies and ultra-pure light sources, we offer compact form factor solutions with seamless integration, cost efficiency, low power, and security of supply. By leveraging established microelectronics ecosystems, we aim to make our products affordable and available in high volumes to address the challenges in 5G and beyond, access-ready coherent solutions, and cloud and cloud edge services. For more information, please visit: www.effectphotonics.com. Follow EFFECT Photonics on LinkedIn and Twitter.
Media Contact:
Colleen Cronin
EFFECT Photonics
colleencronin@effectphotonics.com

EFFECT Photonics Unveils Development of Pico Tunable Laser Assembly Enabling QSFP28 100G ZR Coherent Pluggable Modules
-New pTLA to offer industry-best combination of size, affordability, and performance to meet the demand…
-New pTLA to offer industry-best combination of size, affordability, and performance to meet the demand for 100G coherent at the edge
EINDHOVEN, The Netherlands—EFFECT Photonics, a leading developer of highly integrated optical solutions, announced today the development of a new Pico Tunable Laser Assembly (pTLA) to address the growing demand for 100G coherent transceivers in access networks. Tunable lasers are a core component of optical systems enabling dense wavelength division multiplexing (DWDM) which allows network operators to expand their network capacity without expanding the existing fiber infrastructure. Purposely designed for the optical network edge, EFFECT Photonics new pTLA supports both commercial- and industrial-temperature (C-temp and I-temp) operating ranges and offers an ideal combination of power, cost, and size to enable a transceiver form-factors to upgrade the existing infrastructure to a scalable 100 Gbps coherent solution.
According to a recent Heavy Reading survey, 75% of operators believe that 100G coherent pluggable optics will be used extensively in their edge and access evolution strategy. However, market adoption has yet to materialize since affordable and power-efficient 100ZR-based products are currently not available due to stringent size and power consumption requirements that cannot be fulfilled by today’s tunable laser solutions. Designed specifically to address the 100G coherent network edge, EFFECT Photonics’ pTLA will allow coherent pluggables to be deployed more easily and cost effectively in the access domain and will feature optimal laser performance, size and power consumption for a standard QSFP28 form-factor. Furthermore, EFFECT Photonics’ new pTLA utilizes the existing microelectronics ecosystem to allow manufacturing at scale as well as complementary coherent products and services, such as DSPs for those providers in need of a complete transceiver solution.
“Today’s operators need an network edge aggregation strategy that offers the best combination of capacity, cost-effectiveness, and performance to evolve network access effectively, and 100G coherent pluggable optics offer just that, EFFECT Photonics’ new Pico Tunable Laser Assembly will be the only purpose designed tunable laser assembly today to serve this emerging market. helping to easily scale up network edge aggregation capacity and benefit from coherent technology.”
Roberto Marcoccia, CEO, EFFECT Photonics
About EFFECT PHOTONICS
Where Light Meets Digital – EFFECT Photonics is a highly vertically integrated, independent optical systems company addressing the need for high-performance, affordable optic solutions driven by the ever-increasing demand for bandwidth and faster data transfer capabilities.
Using our proprietary digital signal processing and forward error correction technology and ultra-pure light sources, we offer compact form factors with seamless integration, cost efficiency, low power, and security of supply. By leveraging established microelectronics ecosystems, we aim to make our products affordable and available in high volumes to address the challenges in 5G and beyond, access-ready coherent solutions, and cloud and cloud edge services.
For more information, please visit: www.effectphotonics.com. Follow EFFECT Photonics on LinkedIn and Twitter.
To read the Simplified Chinese version click here.
To read the Traditional Chinese version click here.
To read the Japanese version click here.
To read the Korean version click here.
Media Contact:
Colleen Cronin
EFFECT Photonics
colleencronin@effectphotonics.com

EFFECT Photonics Co-Founder Boudewijn Docter to take on a new challenge
Eindhoven, the Netherlands – Earlier this week, Boudewijn Docter, announced that he was stepping down…
Eindhoven, the Netherlands – Earlier this week, Boudewijn Docter, announced that he was stepping down as President and Director of EFFECT Photonics at the end of January.
Boudewijn co-founded EFFECT Photonics with Tim Koene 13 years ago and since then has been building a company that started out of a lab at the TU/e and has grown into an internationally respected player in the field of photonic integrated technology.
Commenting on his decision, Boudewijn said: “I’m immensely proud of what we have achieved so far. Although the adventure is far from over, I feel that the team is ready to guide the company through the next cycle of growth. For me, this is a natural time to hand over my daily activities in the management team to my colleague Roberto Marcoccia and his team.”
Today it was announced that Boudewijn would be joining HighTechXL, a venture building/start-up accelerator focused on deep-tech technology as their Chief Growth Officer. As Chief Growth Officer, Boudewijn will work to inspire, support, and coach newly created HTXL ventures, helping them become investor-ready by the end of their nine-month venture-building program. While this will be Boudewijn’s main focus, he will still be available in an advisory capacity and also continue to represent EFFECT Photonics in the Dutch photonics ecosystem.
On behalf of everyone at EFFECT Photonics, we want to thank Boudewijn for everything that he has done and meant for the company. We wish him every success in this next chapter and in his new role, and we look forward to continuing the EFFECT Photonics journey with him but then in a slightly different way.


EFFECT Photonics Partners with Fabrinet to Scale Production of Highly Integrated Optical Solutions
EINDHOVEN, The Netherlands—EFFECT Photonics, a leading developer of highly integrated optical solutions, announced today that…
EINDHOVEN, The Netherlands—EFFECT Photonics, a leading developer of highly integrated optical solutions, announced today that it has selected Fabrinet (NYSE: FN) as its manufacturing partner for its integrated optical sub-assemblies.
Fabrinet is a global leader in high-precision optical, electronic and mechanical manufacturing services, and a proven partner for original equipment manufacturers (OEMs) worldwide. As a manufacturing partner, Fabrinet will perform sourcing, procurement, assembly, test, and calibration of EFFECT Photonics’ integrated optical sub-assemblies.
Increased optical bandwidth is needed more than ever before due to a wide range of cloud and cloud edge applications and the increased access speeds enabled by 5G and beyond. Photonics are ideally suited to serve this need, but production currently plays an important role in bringing integrated optics technology to the masses. By leveraging Fabrinet’s leadership in electro-optical and electronics manufacturing, EFFECT Photonics can adapt and scale its integrated optical solutions to meet ever-changing market demands and high-volume requirements.
“Fabrinet is recognized worldwide for its best-in-class expertise in the field of optical product manufacturing and its ability to support the most demanding markets, technologies, and business models. By leveraging their proven capabilities and longstanding manufacturing prowess, EFFECT Photonics is able to offer our customers increased supply, reliability, efficiency and cost-effectiveness.”
Roberto Marcoccia, CEO, EFFECT Photonics.
“We are pleased to have been selected by EFFECT Photonics as their manufacturing partner to provide production at scale for their optical subassemblies. As a leader in advanced optical packaging and precision manufacturing for complex devices, we are well positioned to support EFFECT Photonics in achieving their business goals.”
Edward Archer, Executive Vice President Sales & Marketing at Fabrinet.
About EFFECT Photonics
Where Light Meets Digital – EFFECT Photonics is a highly vertically integrated, independent optical systems company addressing the need for high-performance, affordable optic solutions driven by the ever-increasing demand for bandwidth and faster data transfer capabilities.
Using our proprietary digital signal processing and forward error correction technology and ultra-pure light sources, we offer compact form factors with seamless integration, cost efficiency, low power, and security of supply. By leveraging established microelectronics ecosystems, we aim to make our products affordable and available in high volumes to address the challenges in 5G and beyond, access-ready coherent solutions, and cloud and cloud edge services.
For more information, please visit: www.effectphotonics.com. Follow EFFECT Photonics on LinkedIn and Twitter.
About Fabrinet
Fabrinet is a leading provider of advanced optical packaging and precision optical, electro-mechanical, and electronic manufacturing services to original equipment manufacturers of complex products, such as optical communication components, modules and subsystems, automotive components, medical devices, industrial lasers and sensors. Fabrinet offers a broad range of advanced optical and electro-mechanical capabilities across the entire manufacturing process, including process design and engineering, supply chain management, manufacturing, advanced packaging, integration, final assembly and testing. Fabrinet focuses on production of high complexity products in any mix and any volume. Fabrinet maintains engineering and manufacturing resources and facilities in Thailand, the United States of America, the People’s Republic of China, Israel and the United Kingdom. For more information, please visit www.fabrinet.com.
# # #
Media Contacts:
Colleen Cronin
EFFECT Photonics
colleencronin@effectphotonics.com

Day of Photonics 2022, Photonics FAQ
On October 21st, 1983, the General Conference of Weights and Measures adopted the current value…
On October 21st, 1983, the General Conference of Weights and Measures adopted the current value of the speed of light at 299,792.458 km/s. To commemorate this milestone, hundreds of optics and photonics companies, organizations, and institutes all over the world organize activities every year on this date to celebrate the Day of Photonics and how this technology is impacting our daily lives.
At EFFECT Photonics, we want to celebrate the Day of Photonics by answering some commonly asked questions about photonics and its impact on the world.

What is photonics?
Photonics is the study and application of photon (light) generation, manipulation, and detection, often aiming to create, control, and sense light signals.
The term photonics emerged in the 60s and 70s with the development of the first semiconductor lasers and optical fibers. Its goals and even the name “photonics” are born from its analogy with electronics: photonics aims to generate, control, and sense photons (the particles of light) in similar ways to how electronics does with electrons (the particles of electricity).
What is photonics used for?
Photonics can be applied in many ways. For the Day of Photonics, we will explore two categories:
Communications
Light is the fastest information carrier in the universe and can transmit this information while dissipating less heat and energy than electrical signals. Thus, photonics can dramatically increase the speed, reach, and flexibility of communication networks and cope with the ever-growing demand for more data. And it will do so at a lower energy cost, decreasing the Internet’s carbon footprint.
A classic example is optical fiber communications. The webpage you are reading was originally a stream of 0 and 1s that traveled through an optical fiber to reach you.
Outside of optical fibers, photonics can also deliver solutions beyond what traditional radio communications can offer. For example, optical transmission over the air could handle links between different sites of a mobile network, links between cars, or to a satellite out in space. At some point, we may even see the use of Li-Fi, a technology that replaces indoor Wi-Fi links with infrared light.
Sensing
There are multiple sensing application markets, but their core technology is the same. They need a small device that sends out a known pulse of light, accurately detects how the light comes back, and calculates the properties of the environment from that information. It’s a simple but quite powerful concept.
This concept is already being used to implement LIDAR systems that help self-driving cars determine the location and distance of people and objects. However, there is also potential to use this concept in medical and agri-food applications, such as looking for undesired growths in the human eye or knowing how ripe an apple is.
Will photonics replace electronics?
No, each technology has its strengths.
When transmitting information from point A to B, photonics can do it faster and more efficiently than electronics. For example, optical fiber can transmit information at the speed of light and dissipate less heat than electric wires.
On the other hand, since electricity can be manipulated at the nanometer level more easily than light, electronics are usually better for building computers. There are some specific areas where photonic computers could outperform traditional electronic ones, especially given the rise of quantum computers that can be made with photonic components. However, most computer products will remain electronic for the foreseeable future.
Thus, photonics is not expected to replace electronics but to collaborate and integrate strongly with it. Most future applications will involve photonic systems transmitting or sensing information then processed by electronic computers.
Tags: DayofPhotonics2022, Integrated Photonics, Photonics
‘National Coalition for Sustainable Digitalization’ calls on the government to take an integrated approach to sustainable digitalization
National approach must make the Netherlands an international leader in sustainable digitalization New coalition wants…
- National approach must make the Netherlands an international leader in sustainable digitalization
- New coalition wants long-term vision and short-term action to digitalize more sustainably
- An integrated approach must offer a solution for fragmented government policy at the interface of the two major transitions of digitalization and sustainability.
Amsterdam, 18 October 2022 – The ‘National Coalition for Sustainable Digitalization‘ (NCDD) today offers Minister Adriaansens of the Ministry of Economic Affairs and Climate Policy (EZK) a manifesto that encourages the creation of an integrated approach for sustainable digitalization. By developing and applying digital technologies and data, with an eye for integrating digital infrastructure and combating climate change, other negative environmental effects and impact on raw materials, the proposal outlines how the Netherlands can become a leader in international education. Supported by a coalition of more than 70 organizations, together with the government, the business community, knowledge institutions and residents, the integrated approach capitalizes on existing opportunities, solves bottlenecks and develops a roadmap for a sustainable and eco-friendly digital infrastructure footprint.
The new coalition stems from the Amsterdam Economic Board initiative ‘LEAP’. Together with ECP | Platform for the Information Society and the Sustainable Digital Infrastructure Alliance (SDIA), the coalition seeks to work closely together with government agencies in public-private partnerships and establish the Netherlands as a key contributor to identifying a sustainable future for digital systems worldwide.
Bottlenecks and recommendations in sustainable digitalization
The coalition has formed the basis for a “Roadmap for Sustainable Digitalization which identifies current bottlenecks and solutions for how best to address these challenges. Recommendations include:
- Clear ownership under the stewardship of one coordinated ministry
- Increased utilization of data-driven insights to make optimal considerations relating to digitalization and sustainability
- Suggested amendments to the current transition legislation to ensure sustainable solutions are being adopted in next-generation digital systems
- Knowledge campaigns that provide tools and resources to help educate the importance of sustainable digitalization
- Increased access to innovation, with a focus on the integration of the energy system and digital system and special attention to software, hardware and data processing
- Expansion of the Netherlands’ role in the European conversation about sustainable digitalization.
“The clock is ticking. Digitalization is an essential part of sustainability and digitalization must also be sustainable. Our coalition knows better than anyone what opportunities there are, but also which bottlenecks we have to solve. We cannot do that without this government. It’s time for collective decisiveness,” says Eske van Egerschot-Montoya Martinez, Quartermaster of the National Coalition for Sustainable Digitalization.
The sustainability of digitalization is essential in maintaining the leading position in the Netherlands
Digitalization plays an important role in developing economic resilience and resilience, both now and in the future. In addition, it is key in accelerating economic and ecological sustainability. While the Netherlands currently occupies the fourth position in the EU leading group, making digitalization more sustainable must secure and further expand this position for the future.
“The digital sector has been very active and successful in recent years on the theme of sustainability. We have shown major efficiency improvements in the field of energy and raw materials. In order to continue to do that in the future, we need to step up our game and work together with all stakeholders. The new coalition will help us with that,” says Lotte de Bruijn, Director of NLdigital.
About the NCDD
The NCDD (National Coalition for Sustainable Digitalisation) stems from the
Amsterdam Economic Board initiative ‘LEAP’. Together with ECP | Platform for the Information Society and the Sustainable Digital Infrastructure Alliance (SDIA), in a public-private coalition of more than 70 organizations from government, business, knowledge institutions and residents, they work on the foundations of the Netherlands as an international sustainable digital leader.
‘Nationale Coalitie Duurzame Digitalisering’ roept overheid op tot integrale aanpak duurzame digitalisering
18 October 2022
- Nationale aanpak moet Nederland internationaal koploper duurzame digitalisering maken
- Nieuwe coalitie wil langetermijnvisie en kortermijnactie om duurzamer te digitaliseren
- Integrale aanpak moet oplossing bieden voor versnipperd overheidsbeleid op het raakvlak van de twee grote transities van digitalisering en verduurzaming.
Amsterdam, 18 oktober 2022 – De ‘Nationale Coalitie Duurzame Digitalisering’ (NCDD) biedt minister Adriaansens (EZK) vandaag een manifest aan dat aanzet tot het maken van een integrale aanpak voor duurzame digitalisering. Door het ontwikkelen en toepassen van digitale technologieën en data, met oog voor het inpassen van digitale infrastructuur en het bestrijden van klimaatverandering, andere negatieve milieueffecten en impact op grondstoffen, moet Nederland internationaal duurzaam digitaal koploper worden. De coalitie van ruim 70 organisaties wil hiervoor samen met overheid, bedrijfsleven, kennisinstellingen en inwoners, bestaande kansen verzilveren, knelpunten oplossen en een routekaart ontwikkelen. Zo moet de transitie naar een duurzame digitale infrastructuur worden versneld en de ecologische footprint van ons digitale systeem worden geminimaliseerd.
De nieuwe coalitie komt voort uit het Amsterdam Economic Board initiatief ‘LEAP’. Samen met ECP | Platform voor de Informatiesamenleving en de Sustainable Digital Infrastructure Alliance (SDIA) wordt in publiek-private samenwerking verder gewerkt aan de fundamenten van Nederland als internationaal duurzaam digitaal koploper.
Knelpunten en aanbevelingen bij duurzame digitalisering
De coalitie identificeert zes knelpunten en beveelt oplossingen aan. Deze moeten de basis vormen voor een ‘Routekaart Duurzame Digitalisering’. Zo is er momenteel sprake van incoherent en versnipperd overheidsbeleid, een gebrek aan cijfers om integraal op te sturen, gebrekkige wetgeving, versnipperde kennisontwikkeling en innovatie, en ontbreekt het aan een eerlijk Europees speelveld.
Om deze knelpunten op te lossen draagt de coalitie aanbevelingen aan:
- Eenduidig eigenaarschap in de vorm van één coördinerend ministerie
- Meer op data sturen om inzicht te krijgen om de optimale afwegingen te maken op het raakvlak van digitalisering en duurzaamheid
- Aanpassing nodig van (bestaande) (transitie)wet- regelgeving die ervoor zorgen dat duurzame keuzes vanzelfsprekend gemaakt worden
- Een kennisoffensief dat zorgt voor tools, kennis en mensen
- Zal toegang tot innovatie laagdrempeliger moeten worden, met een focus op integratie van het energiesysteem en digitale systeem, met speciale aandacht voor software, hardware en dataverwerking
- Ook zal Nederland nog zichtbaarder moeten worden in het Europese gesprek over duurzame digitalisering.
“De klok tikt door. Digitalisering is een essentieel onderdeel van verduurzaming en de digitalisering moet ook duurzaam zijn. Onze coalitie weet als geen ander welke kansen er zijn, maar ook welke knelpunten we moeten oplossen. Dat kunnen we niet zonder deze regering. Het is tijd voor collectieve daadkracht.”, aldus Eske van Egerschot-Montoya Martinez, Kwartiermaker van de Nationale Coalitie Duurzame Digitalisering.
Verduurzaming digitalisering essentieel in behouden koppositie Nederland
Digitalisering speelt een belangrijke rol in het ontwikkelen van economische veerkracht en weerbaarheid. Nu en in de toekomst. Daarnaast vormt het een sleutel in het versnellen van economische en ecologische verduurzaming. Waar Nederland momenteel een vierde positie in de EU-kopgroep bekleedt, moet het verder verduurzamen van digitalisering deze positie voor de toekomst veiligstellen en verder uitbouwen. “De digitale sector is de afgelopen jaren heel actief en succesvol geweest op het thema duurzaamheid. We hebben grote efficiencyverbeteringen laten zien op het gebied van energie en grondstoffen. Om dat in de toekomst te blijven doen, moeten we een tandje bijschakelen en samenwerken met de hele keten. De nieuwe coalitie gaat ons daarbij helpen”, aldus Lotte de Bruijn, directeur NLdigital.
Over de NCDD
De NCDD (Nationale Coalitie Duurzame Digitalisering) komt voort uit het
Amsterdam Economic Board initiatief ‘LEAP’. Samen met ECP | Platform voor de Informatiesamenleving en de Sustainable Digital Infrastructure Alliance (SDIA) werken zij, in een publiek-private coalitie van ruim 70 organisaties vanuit overheid, bedrijfsleven, kennisinstellingen en inwoners, aan de fundamenten van Nederland als internationaal duurzaam digitaal koploper.
Tags: data processing, European, EZK, Ministry of Economic Affairs and Climate Policy, National Coalition for Sustainable Digitalization, National Coalition for Sustainable Digitization, NCDD
EFFECT Photonics to Deliver Rural 5G Fixed Wireless Access in Wales
As part of the Welsh Government’s efforts to ensure all residents have access to fast…
As part of the Welsh Government’s efforts to ensure all residents have access to fast and reliable digital infrastructure, EFFECT Photonics is assisting with the roll out of 5G Fixed Wireless Access (FWA) services in hard-to-reach areas in Wales. Led by Vodafone, the project seeks to deliver broadband connectivity to 422 households in Anglesey, an island off the northwest coast of Wales. This is the latest collaboration between EFFECT Photonics and Vodafone, with the two companies already working together to bring 5G connectivity in the Netherlands.
The project will be carried out over two phases during an 18-month period. It is supported by the government’s Local Broadband Fund (LBF) as well as the Isle of Anglesey County Council and North Wales Economic Ambition Board. In addition to EFFECT Photonics and Vodafone, Bangor University’s Digital Signal Processing (DSP) Centre for Excellence is a supplier along with others. EFFECT Photonics and Bangor University have also partnered on the DESTINI project, for the development of an algorithm which can be introduced into existing telecommunications networks to expedite 5G connectivity.
“Photonics technology is an ideal solution for fixed wireless access due to its ability to provide increased bandwidth density with less energy consumption over significant distances,” said Joost Verberk, Director of Product Management, EFFECT Photonics. “We look forward to collaborating with the Welsh government, along with Vodafone and Bangor University once again, to bring 5G broadband access to areas never seemed possible before.”
EFFECT Photonics SFP+ Modules and NarroWave Technology
Based on Indium Phosphide technology, the EFFECT Photonics 10 Gbps Narrow Tunable SFP+ Transceiver Module leverages the company’s unique Photonics Integrated Circuit (PIC) technology. It features EFFECT Photonics NarroWave technology, which allows operators to set up, monitor and control remote SFP+ modules from the central office, without making any hardware or software changes in the field.
Tags: 5G, access networks, coherent, connectivity, cost-effective, DESTNI, DWDM, FWA, integration, NarroWave, network, Networks, photonic integration, Photonics, pluggable, reach, telecommunication, Transceiver, Tunable SFP+, Vodafone, Wales, Welsh, Welsh Government
EFFECT Photonics Names Roberto Marcoccia Interim CEO
EFFECT Photonics announced today the appointment of Roberto Marcoccia as Interim Chief Executive Officer, effective…

VodafoneZiggo Partners with EFFECT Photonics for 5G Connectivity on Existing Dutch DWDM Networks
Tunable SFP+ modules powered by photonics System-on-Chip (SoC) technology successfully tested on live Dutch network…

ISO 9001 certification reaffirms EFFECT Photonics’ commitment to quality across operations
As a leading provider of highly integrated photonics solutions for optical communication products, EFFECT Photonics…

EFFECT Photonics Opens Regional Americas Headquarters in Maynard, MA
EFFECT Photonics, a leading developer of integrated coherent optics solutions, has opened its Americas Headquarters…
EFFECT Photonics, a leading developer of integrated coherent optics solutions, has opened its Americas Headquarters in Maynard, Massachusetts. The new facility provides further support for North and South American customers and partners as well as for global customers with operations in the region.
The Maynard facility expands EFFECT Photonics’ engineering, product testing and verification, customer support and marketing capacity to complement the company’s European and Asia Pacific teams. It includes engineering design space, state-of-the-art application laboratory, demo space and office space to rapidly address customer needs and the design and development of affordable, innovative photonic solutions.
“Photonics represents one of the fastest-growing industries as it provides an ideal solution to respond to the soaring demand of higher bandwidth and enable increased interconnectivity to make people’s lives better and easier,” said James Regan, CEO, EFFECT Photonics. “With the opening of our new Americas headquarters, EFFECT Photonics is well-suited to meet worldwide demand and able to realize our goal of becoming a global company.”
EFFECT Photonics aims to democratize photonics technology by making complex high-performance optical systems simpler and more affordable for a variety of industries including telecommunications, aerospace, lidar and quantum technology. With the company’s recent acquisition of ViaSat’s coherent digital signal processing business, EFFECT Photonics is the only independent supplier to that can offer the entire coherent optics stack, thereby enabling the company to provide customers with optimized designs that feature advantages in cost and power per bit. In addition, EFFECT Photonics is working on industry-leading subcomponents such as DSP, tunable lasers (iTLAs) as well as full modules for direct detect solutions. The continued growth of the company’s product portfolio and American customer base provides many career opportunities. To view current openings, please visit effectphotonics.com/careers.
“At EFFECT Photonics, we offer challenging work, great career opportunities at a fast-growing company, a welcoming culture, and the chance to work on disruptive technologies that are shaping the art of the possible in communications and beyond,” said Roberto Marcoccia, Chief Development Officer, EFFECT Photonics. “Our new regional headquarters provides an excellent work environment for our employees and offers us the opportunity to be at the heart of one of our largest markets and be closer to our customers and partners in the Americas.”
About EFFECT Photonics
EFFECT Photonics is a highly vertically integrated, independent leader in integrated optics, addressing the need for high-performance, affordable solutions driven by the ever-increasing demand for bandwidth and faster data transfer capabilities. EFFECT Photonics is headquartered in Eindhoven, The Netherlands, with additional facilities in the UK, the US and Taiwan, and a worldwide network of sales partner. www.effectphotonics.com
# # #
Press Contact:
Colleen Cronin
EFFECT Photonics
colleencronin@effectphotonics.com
Tags: America, Boston, Integrated Photonics, Massachusetts, Maynard, photonic integration, US
EFFECT Photonics Closes the Acquisition of the Coherent Optical Digital Signal Processing Business from Viasat
EFFECT Photonics Closes the Acquisition of the Coherent Optical Digital Signal Processing Business from Viasat…

PhotonDelta secures €1.1 billion to usher in a new generation of semiconductor technology
Capital from the Netherland’s Ministry of Economic Affairs and Climate Policy and other organizations will…
- Capital from the Netherland’s Ministry of Economic Affairs and Climate Policy and other organizations will be used to build 200 startups, scale up production, create new applications for photonic chips and develop infrastructure and talent
- Photonic chips enable the creation of devices that are substantially faster, cheaper to produce, and use considerably less electricity
- Development of photonic tech will tackle societal challenges such as sustainability, create a new European industry, and open the door to a huge range of new applications including quantum computing
Eindhoven, The Netherlands; April 14 2022
PhotonDelta, a cross-border ecosystem of photonic chip technology organizations, has secured € 1.1 billion in public and private investment to transform the Netherlands into the leader of the next generation of semiconductors.
The investment includes €470 million of funding obtained through the National Growth Fund (Nationaal Groeifonds), while the rest is co-invested by various partners and stakeholders. It is part of the Dutch Government’s national plan to cement and expand the country’s position as a world leader in integrated photonics.
The program will run for six years and will enable PhotonDelta and its partners to further invest in photonic startups and scaleups, expand production and research facilities, attract and train talent, drive adoption, and develop a world-class design library. By 2030, PhotonDelta aims to have created an ecosystem with hundreds of companies, serving customers worldwide and a wafer production capacity of 100,000+ per year.
Photonics uses photons (light) to transfer information. Photonic chips, also called photonic integrated circuits (PICs), integrate photonic functions into microchips to create smaller, faster and more energy-efficient devices. PICs can process and transmit data much more effectively than their electronic counterparts. Just like with traditional chips, the production process is carried out using automatic wafer-scale technology. This allows the chips to be mass-produced, reducing costs.
Crucially, PICs can overcome the expected limit to Moore’s Law and will also help tackle energy sustainability issues. PICs are currently used in the data and telecom industry to reduce the energy consumption per bit and increase speeds. With data and internet use expected to be around 10% of global electricity consumption by 2027, PICs provide a powerful way to limit the impact on the climate. Photonic circuits will also soon play an important role for innovative sensors that can be mass-produced, leading to earlier diagnostics of diseases, safe autonomous vehicles and infrastructure, and more efficient food production.
Ewit Roos, CEO at PhotonDelta, said: “This investment is a game-changer. It will make the Netherlands the home of the next generation of semiconductors which will have a profound impact on the whole European tech industry.
“The ongoing chip shortage highlights the pressing need for Europe to create its own production capabilities for strategic technologies. We will now be able to support hundreds of startups, researchers, producers and innovators to boost this industry that will be as impactful as the introduction of microelectronics a few decades ago.
“The Netherlands is considered a pioneer in the development of PIC technology, and thanks to the continuous support from the Dutch government, we have been able to build a full supply-chain around it that is globally recognized as a hotspot for photonic integration.
“Photonic chips are one of the most important technological breakthroughs of the last decade. Not only do they allow for the creation of devices that are faster, cheaper, more powerful and greener – they also enable radical new innovations like affordable point-of-care diagnostics or quantum computing to become a reality.”
“EFFECT Photonics is honored to be part of the allocation of the National Growth Fund. It is an exciting time for our industry and this kind of on-going support and funding from the Dutch government will bring the maturity and scalability of the Dutch photonics eco-system to the next level and allow us to compete on truly global scale.
For EFFECT Photonics this means that that we will be able to build on our ambition to make photonics simpler, more accessible, and affordable as we further the development of our next generation coherent solutions including the integration of our recently acquired DSP capabilities.
Our thanks go to the Ministry of Economic Affairs and Climate for making this possible and to PhotonDelta for their guidance, organization, and coordination. We very much look forward to working together in the coming months and years to further drive innovations and value in our industry.” – Boudewijn Docter at President EFFECT Photonics.
The PhotonDelta proposal has been submitted by the Dutch Ministry of Economic Affairs & Climate Policy in close collaboration with Eindhoven University of Technology (TU/e), University of Twente (UT), Delft University of Technology (TUD), Holst Centre, TNO, IMEC, PITC, CITC, OnePlanet, SMART Photonics, LioniX International, EFFECT Photonics, MantiSpectra, PhotonFirst, PHIX, and BRIGHT Photonics.
The PhotonDelta ecosystem currently consists of 26 companies, 11 technology partners and 12 R&D partners. The organization is part of a consortium which has jointly invested €171 million in promising photonics companies including SMART Photonics, PhotonFirst, Surfix, MicroAlign, Solmates and EFFECT Photonics.
ENDS
Notes to Editor
*Conditions include:
- Strategic partnership with a foundry agreed
- Research activity connected with applications of technology
- Ongoing evaluation of PhotonDelta’s ecosystem
Example applications of PICs:
Data & Telecoms: The biggest challenge within this domain is the high energy consumption of data infrastructure. Without any savings made, the share of data and internet use is expected to be around 10% of global electricity consumption by 2027. This includes energy consumption by end-users on the one hand and data centers on the other. 5G, the Internet of Things, and artificial intelligence will further accelerate this. Photonics provides gains in speed, weight, and energy consumption.
Healthcare: The development of mobile, wearable photonic devices (combined with advanced biosensors for direct point-of-care diagnostics and treatment that measure the medical condition and well-being of the wearer) can contribute to early detection and diagnosis of diseases, as well as an earlier and more targeted treatment. Photonics will eliminate the need for a visit to the hospital for many treatments or consultations.
Mobility: The biggest challenge in automotive in the near future lies in the availability of affordable sensors to enable autonomous driving at various stages. With the advantages of photonic chips (weight, speed, cost), the possibilities for self-driving transport are increasing. This has positive implications for road safety and lost travel time is made available again. Photonics can also mean a lot for battery management in electric vehicles and the control of traditional cars. For the aircraft industry, the emphasis is on sensor systems.
AgriFood: To feed a world population that is expected to reach 10 billion by 2050, a drastic increase in food production is needed. But this must be done in a sustainable way: without excess nitrogen or excess CO2 emissions and preferably also in a way in which animal proteins have made way for vegetable proteins. In addition, food safety is an important precondition. The solution lies in precision agriculture, something in which photonics can play a major role. Sensor systems that run on photonics ensure that all requirements regarding safety, health, and sustainability can be met.
Full list of PhotonDelta partners (47):
Core partners (supply-chain) 25: LioniX International BRIGHT Photonics SMART Photonics PHIX PhotonFirst Aixscale Photonics EFFECT Photonics Pilot Photonics QuiX Quantum Delta Diagnostics Surfix Diagnostics Nostics EFI Instruments Amazec VTEC lasers & sensors MantiSpectra OmmatidiaLidar Demcon Memscan Neuruno Deloq Fuqon Tarucca Aircision | Suppliers (technology partners) 11: Bruco ASML Aixtron Solmates Chip Integration Technology Center (CITC) Etteplan Tyndall Salland Engineering TNO IMS MicroAlign | R&D partners (12): Photonic Integration Technology Center (PITC) University of Twente Eindhoven University of Technology TU Delft Imec Holst Centre OnePlanet Waterloo Institute of Nanotechnology TNO Fraunhofer HHI MIT HighTech XL |
Technical information on photonics tech: https://www.photondelta.com/how-it-works/
More detail on how the investments will be used:
The goal is for accelerated, far-reaching further development of the photonics ecosystem and industrial development. Spread over 3 axes:
- Accelerated industrialization: scaling up and optimizing production processes, new factories and integration with other platforms, such as CMOS or SiPh via ChipLet technology
- Application technology: developing new applications via building blocks to meet major societal (and industrial) challenges
- Ecosystem development: strengthening the ecosystem with targeted investments in weak spots: support startups, scale-ups, campus development, talent development, shared infrastructure for development, access for new entrants
About PhotonDelta
PhotonDelta is an ecosystem that researches, designs, develops, and manufactures solutions with integrated photonics technology. Connecting pioneers in the field with investors, and viable markets, PhotonDelta helps to take the industry forward with funding, investments and R&D roadmaps. PhotonDelta is located in the Netherlands but connects and collaborates throughout Europe. www.photondelta.com
Background PhotonDelta organisation
In December 2018, a covenant was signed in which Dutch companies, knowledge institutions and governments pool a total of € 236 million in cash and in-kind resources, with the aim of exploiting the leading knowledge position in the field of integrated photonics and thus creating a strong economic position in the world.
The PhotonDelta partners together form a cohesive and co-operative industrial cluster. The ambitions and strategy for 2019-2026 are laid down in the PhotonDelta National Plan of the Dutch government, which is structured along four strategic pillars. The PhotonDelta Foundation is the implementing organization for this plan and started its activities on 1 January 2019.


EFFECT Photonics Acquires Coherent Optical Digital Signal Processing Business from Viasat
EFFECT Photonics to Become the Most Highly Vertically Integrated, Independent Coherent Optical Module Vendor San…
EFFECT Photonics to Become the Most Highly Vertically Integrated, Independent Coherent Optical Module Vendor
San Diego, United States America, 8 March 2022 – Today at OFC (Optical Fiber Conference) 2022, EFFECT Photonics, a leading provider of highly integrated optical communication products is announcing that it signed a definitive agreement to acquire coherent optical digital signal processing (DSP) and forward error correction (FEC) technology as well as a highly experienced engineering team from global communications company, Viasat Inc. (NASDAQ: VSAT).
Viasat is a long-established player in DSP and FEC technology. With eight generations of design IP, they have a proven track record of delivering successful field deployments.
From this acquisition, EFFECT Photonics will now own the entire coherent technology stack of all optical functions, including a high-performance tunable laser, together with DSP and FEC. This will enable the Company to deliver on its ambition to make high performance coherent communications solutions widely accessible and affordable. Furthermore, it will enable longer term economic and environmentally sustainable communications due to the ability to deliver high-end performance and reach within a small footprint and with lower power consumption. This opens the way to drive coherent technology into new places, revolutionizing the way the world interconnects.
This transaction is expected to provide the following customer benefits:
- EFFECT Photonics will be able to optimize the complete solution for any application addressing both existing challenges and new possibilities
- With full ownership of the key optical, DSP and FEC functions, EFFECT Photonics can offer seamless integration, cost efficiency and security of supply
- EFFECT Photonics will be an independent vendor able to offer a full portfolio of building blocks such as the tunable laser and DSP, and/or complete solutions, increasing the choice reduced by recent mergers and acquisitions in the industry
EFFECT Photonics has also secured an additional $20M in Series-C funding bringing the total to $63M. Additionally, pursuant to the DSP acquisition agreement, Viasat will be joining EFFECT Photonics’ Supervisory Board and hold a minority interest in the Company.
“This is a significant step in accelerating our ambition to make coherent optical communications ubiquitous and further drive our product portfolio growth. We look forward to welcoming the team of highly skilled and experienced design architects and engineers who will be joining us to drive the development of energy efficient, high performance and affordable coherent solutions.
James Regan, CEO EFFECT Photonics.
With all the recent changes in the industry landscape, this means that EFFECT Photonics is the only independent vendor able to deliver both the active optical components and the DSP. This will offer the market more choice and the ability to source superior solutions“
“Given the trend of the fiber optic communications industry towards consolidation to provide vertically integrated end-to-end solutions, we believe that combining Viasat’s assets and capabilities with the unique integrated photonics capabilities of EFFECT Photonics will create substantially more market opportunities and better products. By investing in this Netherlands-headquartered company, we will also further expand our presence in Europe and be able to partner with EFFECT to bring state-of-the-art integrated photonics to Viasat’s own customers.”
Russell Fuerst, business area leader and vice president, Viasat.
–End of press release–
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for affordable DWDM solutions driven by the soaring demand for high bandwidth connections. EFFECT Photonics is headquartered in The Netherlands, with additional facilities in the UK, the US and Taiwan, and a worldwide network of sales partners. http://www.effectphotonics.com
About Viasat
Viasat is a global communications company that believes everyone and everything in the world can be connected. For more than 35 years, Viasat has helped shape how consumers, businesses, governments and militaries around the world communicate. Today, the Company is developing the ultimate global communications network to power high-quality, secure, affordable, fast connections to impact people’s lives anywhere they are—on the ground, in the air or at sea. To learn more about Viasat, visit: www.viasat.com, go to Viasat’s Corporate Blog, or follow the Company on social media at: Facebook, Instagram, LinkedIn, Twitter or YouTube.
Copyright © 2022 EFFECT Photonics. All rights reserved. Viasat, the Viasat logo and the Viasat signal are registered trademarks of Viasat, Inc. All other product or company names mentioned are used for identification purposes only and may be trademarks of their respective owners.
Tags: acquisition, coherent, coherent communication systems, coherent optical module vendor, DSP, FEC, forward error correction, high vertical integration, independent coherent optical module vendor, Integrated Photonics, optical digital signal processing, optical engine, tunable laser, Viasat
EFFECT Photonics and Jabil Photonics to Co-Develop Next-Generation Coherent Module
EFFECT Photonics and Jabil Photonics, a business unit of Jabil Inc. (NYSE: JBL), announced today…

EFFECT Photonics joins the SmartTunable MSA Group
EFFECT Photonics announced today that it has joined the SmartTunable Multi-Source Agreement (MSA) group. This…

Aircision and EFFECT Photonics to jointly develop coherent technology for free space optics
Aircision builds high capacity free space optics (FSO) systems that can be deployed fast, cover…
Aircision builds high capacity free space optics (FSO) systems that can be deployed fast, cover long distances and are highly secure. In December 2021, Aircision successfully demonstrated the capabilities of their first 10 Gbps FSO system. EFFECT Photonics is a leading transceiver vendor and able to deliver the flexible, pluggable optical transceiver that is a key component of Aircision FSO system . Together, Aircision and EFFECT Photonics are looking to push the boundaries of ground-to-ground FSO technology by combining the advantages of integrated and free space photonics.
“We were impressed with the capabilities of the EFFECT Photonics 10G SFP+ devices that we tested. It was an easy decision to involve them in our development plans for our next generation 100 Gbps coherent transmission systems” said Luis Oliveira (CEO and co-founder at Aircision). New technologies emerge every day and our digital society will keep evolving. To keep up with the ever-growing demand for bandwidth across larger distances, Aircision is developing a 100 Gbps coherent free space optics system capable of transmitting up to 10km.
Joost Verberk, Director of Product Management at EFFECT Photonics, “As we look to applications outside of pure fiber-based communications, we liked the market use cases Aircision presented as well as the market traction they already have. Our roadmaps follow a similar course making a joint development program an interesting option for EFFECT Photonics.”
Both Aircision and EFFECT Photonics are part of the PhotonDelta eco-system, a platform which is in place to accelerate developments such as this and reduce the time-to-market of new applications.
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for affordable DWDM solutions driven by the soaring demand for high bandwidth connections. EFFECT Photonics is headquartered in Eindhoven, The Netherlands, with additional facilities in the UK, the US and Taiwan, and a worldwide network of sales partners.
About Aircision
Aircision is a deep-tech startup located on the HighTech Campus Eindhoven focused on developing high performing FSO systems for Ground-to-Ground applications. Aircision was founded in early 2019 with support from the Eindhoven Startup Alliance and HighTechXL. For more information, see the Aircision website here.

EFFECT Photonics Announces the Resignation of Dennis Maas, VP of Finance & Infrastructure
EFFECT Photonics today announced that Dennis Maas, Vice President of Finance & Infrastructure, will be…
EFFECT Photonics today announced that Dennis Maas, Vice President of Finance & Infrastructure, will be leaving the company as of March 1st, 2022 to pursue new opportunities.
“Since I joined in 2013, there has been an incredible momentum and I feel privileged to leave this company with an ambitious growth plan in place for the coming years. I am very grateful for this unforgettable journey and want to thank my fellow co-founders Boudewijn Docter, Tim Koene, James Regan, Robert Hughes and all our incredible colleagues and investors for the great experiences and memories! I will continue to support EFFECT Photonics wherever I can and am confident in it will succeed in becoming a big international, Dutch born, success story . At the same time I am extremely excited about the next chapter in my life – more on that soon” – Dennis Maas.
“We would like to thank Dennis for the dedication, energy and expertise he brought to EFFECT Photonics. During his tenure, the company went through several successful funding rounds, the number of employees grew to over 200 and saw the launch of its first products to market. With Dennis’ help, we have laid the foundation for our future success and we wish him all the very best as he goes on to his next chapter.” – Boudewijn Docter, President EFFECT Photonics.
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for affordable DWDM solutions driven by the soaring demand for high bandwidth connections. EFFECT Photonics is headquartered in Eindhoven, The Netherlands, with additional facilities in the UK, the US and Taiwan, and a worldwide network of sales partners. http://www.effectphotonics.com
Tags: Dennis Maas, resignation, VP
Meet the team behind the EFFECT Photonics & Aston University partnership to bring greater bandwidth to a greener future
The optical transceiver market is expected to double in size by 2025, and coherent optical…
The optical transceiver market is expected to double in size by 2025, and coherent optical technology has come a long way over the past decade to become more accessible and thus have a greater impact on this market. When Nortel (later Ciena) introduced the first commercial coherent transponder in 2008, the device was a bulky, expensive line card with discrete components distributed on multiple circuit boards.
Recently, EFFECT Photonics and Aston University announced that they would collaborate as part of the newly formed Royal Academy of Engineering Research Chair in Highly Integrated Coherent Optical Fibre Communications.
To learn more about this industry/academic partnership, we interviewed the three lead researchers in this project: Prof. Wladek Forysiak, Dr. Ian Phillips, and Dr. Stylianos Sygletos.

Tell us a little more about yourself and the team
Wladek: My background goes back almost to the start of the Aston Institute of Photonics Technology (AIPT). AIPT was formed by a couple of guys who came out of British Telecom and what was then part of the GEC Telecom Company. The institute has deep industrial roots, and hence the people who work at AIPT often like to participate in projects close to the industry with relatively short timescales. I joined the institute as a post-doc and then subsequently became an academic staff member.
Around 2000, I left alongside five others for a “virtual startup” with the Marconi company, and we formed an entity called Marconi Solstis. At that time, we developed a record-breaking terrestrial ultra long haul system, and we installed our first system in Australia, linking the cities of Perth and Adelaide. Marconi then morphed into Ericsson, and I stayed there for another six to seven years.
In 2010, I moved to Oclaro (now Lumentum), which does somewhat similar technology to what’s being developed by EFFECT Photonics on their integrated indium phosphide platform. I spent three or four years there before returning to academic life at Aston. As for the team, we have funding for three full-time Ph.D. students we’re currently working to recruit. They will be the cement, the foundation of our project.
Ian: I’m of a similar background to Wladek. My expertise is in transceivers, especially characterization and design. I completed my Ph.D. at Aston in 1997 in optical signal processing. British Telecom (BT) sponsored the project, and I worked there for a year after my Ph.D. Corning subsequently purchased the BT Photonics Lab in 2000, and I stayed there for another year. Afterward, I moved to Marconi Solstis with Wladek and stayed there until 2010, when Ericsson closed the site. I then worked in Italy for two years, transferring some system knowledge to the Ericsson research group there, and finally, I joined Aston in 2012.
Stylianos: I completed my Ph.D. at the National Technical University of Athens in 2006, focusing on the physical layer modeling of optical communication systems. I worked for a year at Athens Information Technology (i.e., a research center of Intracom, the largest telecom system provider in Greece). Between 2007 and 2009, I moved for a post-doc position in the Karlsruhe Institute of Technology, working with Juerg Leuthold to model quantum-dot semiconductor optical amplifiers.
I then moved to the Tyndall National Institute in Ireland in 2009 to join the group of Andrew Ellis. I focused on the design and experimental implementation of phase-sensitive amplifiers and optical phase-locking solutions for these amplifiers.
After 2012, I joined AIPT as a research fellow, where my research interests eventually changed to digital signal processing and machine learning. I want to apply machine learning to the physical layer of optical communication systems. I’m now the director of two Master’s programs at Aston: the Smart Telecom and Sensing Networks (SMARTNET) and the Erasmus Mundus Photonic Integration and Networks (PIXNET), in collaboration with different universities in Europe and Japan.
What attracted you to collaborate with EFFECT Photonics?
Wladek: This project came about through a conversation between James (EFFECT Photonics’ CEO) and myself where he said, “Well, I’m interested in growing research activities to enhance our systems capability, and I have confidence in the experience of you and the Aston team”. So I said to him that one way to build a long-term relationship between a company and a university is through Ph.D. studentships.
AIPT is very much about doing applied research, and James was very much about the value of user-directed research that is close to the market and based on real-world situations. So he and I shared that vision around the partnership.
Another reason was, of course, that EFFECT Photonics has technology complementary to ours. EFFECT can be a source of advanced technology for us to build the best experiments that compete with the best in the world. Our competition is in the advanced labs of Japan, the US, and other areas in Europe, and having access to great components is key to matching their capabilities.
We also found attractive the ambition and drive of a startup company and its ability to make quick decisions. When I reached out to James with ideas, I could get an immediate yes or no answer, often on the call, for authorization.
Ian: James explained to us really well what EFFECT Photonics was doing, its ambitions, and how it aligned with our work. When we visited the facility in Brixham and were shown around the labs, it was all indicative of a company that wanted to get things done quickly, and hopefully, we can help them in that process.
Stylianos: On top of what Wladek already mentioned, it’s great to work with a startup that is more open to testing new technologies. I’m passionate about machine learning, and the prospect of applying machine learning algorithms to EFFECT Photonics’ novel technology platform is very exciting. I feel like there is an opportunity to make a big impact.
In what ways do the facilities of Aston University complement what EFFECT Photonics has?
Wladek: EFFECT Photonics develops advanced components that interest people like us working on optical communication systems and networks. We’re used to thinking about integrating these advanced components into our systems and getting the maximum capacity from point A to B.
We have a history of 30 years with optical fiber transmission, so we have all the necessary facilities for system modeling and testing. Stelios also brings to the party his expertise in DSP software, which is also critical to what EFFECT Photonics may do in the future.
Ian: We also see our job as training the Ph.D. students to pass on our knowledge of system design and how that reflects in EFFECT Photonics’ transceiver design. We want to train the students and get them to creatively and effectively use the components.
Stylianos: It depends on how the project goes, but we can even develop device models of EFFECT Photonics units and identify the device parameters that can meet network and system-level targets. We can even combine it with machine learning for extra optimization of those parameters.
What are some of the main challenges you hope to address?
Wladek: Looking for a greener future is a big challenge in optical comms. We’ve all witnessed it in the last couple of years with the pandemic. We need greater network capacity but also cheaper and greener. We cannot let that demand for capacity just be the same old technology since power consumption would go up and up and up.
The challenges are similar to what they’ve always been, in a way, but even more acute. And we need to do it all without really spending more money. Nobody wants to pay more for their comms at the end of the day.
We should also go in other directions to increase the capacity. For example, EFFECT Photonics’ current components are made for the optical C-band, but people in long-haul and other areas are looking at creating multiband components that can also operate in the L-band. We’ve also got projects currently looking at the S-band and shorter wavelengths. Researchers are also looking at different fibre structures to carry more and more signals.
At the same time, there’s an industry drive never to pay for more. Ultimately, that mindset has driven even more technical innovation. Capacity has gone up, but the price has gone down. It’s a relentless game, and everyone keeps saying there’s going to be a point at which we don’t need any more capacity, but if it’s there, we always find ways of using it.
Ian: One key challenge many companies are working on is increasing the baud rate, which is quite a technical problem. If you increase the baud rate, you increase the channel capacity too. It was stuck at around 28 GBaud for a long time, and now it’s going up 64 and even 100 GBaud.
Stylianos: I want to mention how important is network optimization to improve performance and reduce power consumption, which would lead to greener networks.
Network operators need to maintain large performance margins to secure a robust operation in different network conditions. In practice, however, these margins mean more power consumption. Ideally, you would like to reduce those margins by a more efficient design of your system and performance that can adapt to the different conditions. We can achieve these goals through machine learning.
This requires solutions for multi-objective optimization. For example, we are not just interested in designing the transmitter subsystem, but we want to see how transmitter performance is connected to network-level performance, as measured by throughput and power consumption. This is a complex problem that involves different layers of the system.
Takeaways
Moving towards a higher-capacity and greener future requires strong collaboration between academic and industrial partners with shared goals. EFFECT Photonics and Aston University share a vision around this greener future and the value of applied research.
This joint project will unite EFFECT Photonics’ component development expertise with Aston’s expertise in optical fiber transmission modeling, testing, and network optimization through machine learning. This union can enable faster, more affordable, and sustainable coherent products that give greater bandwidth to a greener future.
As Wladek mentioned in the interview, this joint project is looking for three PhD students to drive it forward, with the positions available to start in March, July, or October 2022. If you are interested in applying or know someone who might be interested, please visit the following link: https://jobs.aston.ac.uk/Vacancy.aspx?ref=R210549 .
Tags: Aston University, bandwidth, coherent, coherent optics, CoherentPIC, digital signal processing, DWDM, Green Energy, optical network, photonic integration, Photonics, programmable optical system-on-chip, Royal Academy of Engineers, sustainability telecommunication energy efficency, Sustainable
EFFECT Photonics on the Top50 EIC ScalingUp list.
EFFECT Photonics is delighted to announce that it is on the list of 50 most…
EFFECT Photonics is delighted to announce that it is on the list of 50 most promising European Deep Tech start-ups as part of the EIC ScalingUp programme. A Selection Committee of experienced investors chose to include EFFECT Photonics from more than 3,000 candidates in a selection process covering several stages. These companies are considered the most promising EIC (European Innovation Council) deep tech companies that have the potential to achieve substantial growth, and to become world-scale companies or to realise a big exit or IPO.
“Through the EIC ScalingUp project the EIC supports high-growth, high potential companies with visionary ideas, disruptive technologies, and the ambition to grow exponentially in Europe and globally.”– Jean-David Malo, Director, European Innovation Council (EIC) and SMEs Executive Agency (EISMEA).
“We are honoured to be part of this select group. Our thanks go to the European Innovation Council, Tech Tour, DeepWave Ventures, Boston Consulting Group and bpifrance for the opportunity to further expand on our ambitions to make complex, powerful optical systems simpler and more accessible.”– James Regan, CEO EFFEFCT Photonics.
To learn more about the EIC ScalingUp programme, please click here.
To download the Top50 Publication, please click here.
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections. EFFECT Photonics is headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, a subsidiary in Taiwan, a facility opening shortly outside Boston, and a worldwide network of sales partners.


EFFECT Photonics winner in the Deep Tech Programme 2021!
Eindhoven, The Netherlands 23 November, 2021 EFFECT Photonics is pleased to share that it has…
Eindhoven, The Netherlands 23 November, 2021
EFFECT Photonics is pleased to share that it has been chosen as one of the 2021 Deep Tech Programme winners.
EFFECT Photonics was one of the 46 selected companies, from a pool of over 300 candidates, presenting their business at the TechTour Deep Tech Programme 2021 (https://techtour.com) on 17-18 November 2021. The main goal was to unite the top deep tech companies in seeking funding with 200+ corporate and VC investors during a focused 2-day online event.

About EFFECT Photonics
For further information please contact sales@effectphotonics.com
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. EFFECT Photonics is headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, a facility opening soon in the Greater Boston Area and sales partners worldwide. www.effectphotonics.com
Tags: Deep Tech, EFFECT Photonics, Photonics, transceiversSFP
EFFECT Photonics pleased to be a participant in the Region Deal Brainport Eindhoven
In 2018, Brainport Eindhoven, via the Region Deal, invested €35 million into helping build and…
In 2018, Brainport Eindhoven, via the Region Deal, invested €35 million into helping build and support the broader PhotonDelta eco-system. EFFECT Photonics was one of the companies that benefited from this support. In the following video, we, together with MantiSpectra and PhotonFirst, introduce our businesses and share how this initiative has helped us grow.
As part of this initiative, the Dutch government, provincial departments, companies and knowledge institutes will invest €236 million in Dutch-based photonics technology in the coming years in order to further develop the technology and remain a global leader in this field. This investment is expected to create around 4000 jobs by 2025.
Our thanks go to PhotonDelta and all the parties involved that made this possible including the Dutch government, the Province of North Brabant, the Brainport Foundation, Brainport Regional Fund and the Municipality of Eindhoven. If you would like to know more, then please visit
https://brainporteindhoven.com/en/discover/strategy/region-deal-brainport-eindhoven
Tags: #invest, Brainport Eindhoven, Integrated Photonics, Investment, optical networking, optical technology, PhotonDelta, photonic integrated chip, photonic integration, PIC, programmable optical system-on-chip, region deal

EFFECT Photonics joins the CableLabs vendor community
EFFECT Photonics today announced it is now able to join CableLabs in collaborating on optical…
EFFECT Photonics today announced it is now able to join CableLabs in collaborating on optical technology projects – aimed at developing optical-related specifications, tools, test suites, software, and documentation – after signing an agreement to the terms of the CableLabs Optical Project Charter.
The primary focus of the project is on the application of optical technologies in the access network, mainly coherent such as coherent passive optical networking (CPON). By working closely with CableLabs and its network of members, EFFECT Photonics will work to create the interoperable products that MSO (Multi System Operators) clients want, as well as helping them get to market faster.
CableLabs is the worldwide, leading R&D lab for the cable industry from the United States, Canada, Mexico, Central & South America, the Caribbean, Europe, Asia, and Australia. It is a crucial source for MSO specifications in areas like DOCSIS technology, Optical Coherent Transmission, Wi-Fi, etc. CableLabs has a number of different working groups and regularly hosts interoperability events, always driven by the needs in the cable industry and sponsored by the MSO companies.
In addition to its MSO members, CableLabs has a long history of vendor community collaboration, teaming up to bring new, innovative ideas to fruition.
EFFECT Photonics’ CCO Harald Graber explains: “MSO networks are constantly evolving to address the growing demand to move more data at higher speeds. We look forward to being an active contributor in helping to address this and future challenges. We believe that our unique optical System-on-Chip technology and packaging competence in both our current direct detect and next gen coherent transceivers, can contribute to achieving the CableLabs community’s goals.”
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. EFFECT Photonics is headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, and a facility opening soon in the US.
http://www.effectphotonics.com
Press contact: press@effectphotonics.com

EFFECT Photonics partners with Aston University to bring greater bandwidth to a greener future
EFFECT Photonics would like to congratulate Professor Wladek Forysiak from Aston University on his recently…
EFFECT Photonics would like to congratulate Professor Wladek Forysiak from Aston University on his recently announced appointment as the Royal Academy of Engineering Research Chair in Highly Integrated Coherent optical fibre Communications.
In this joint industry/academia research partnership, the HICC project will leverage the System-on-Chip technology and expertise in high density photonic integration and manufacturing from EFFECT Photonics. The Wavelength Division Multiplexing (WDM) system design, performance testing and digital signal processing capabilities from Aston University will help further push the boundaries to broker a new era of short-distance optical networking based on “digital coherent” techniques. The aim is to identify and enable new network applications that will take coherent optics into new spaces. By further reducing the cost and power requirements of these components, sub-systems, and systems, this project will contribute to a more sustainable and greener future by providing greater bandwidth to everyone.
“EFFECT Photonics has the unique technology to build a fully integrated coherent optical system on a chip, with world leading energy efficiency that enables high performance in a small module. Prof. Forysiak embodies a distinctive combination of cutting-edge optical systems academic research with extensive industrial sector experience at Marconi, Ericsson and Oclaro, and is embedded within Aston University, one of Europe’s leading universities for optical transmission research. The Royal Academy of Engineering funding and expertise brings these elements together. With this partnership we can build a powerhouse that will push the envelope of very high bandwidth internet close to the user for the benefit of all society. I am very excited about this collaboration!” – James Regan, CEO.
“I am delighted to be supported by The Royal Academy of Engineering, EFFECT Photonics, and Aston University to work on the HICC project, together with my close colleagues, Dr Ian Phillips and Dr Stelios Sygletos. The complimentary expertise of EFFECT Photonics in highly integrated System-on-Chip photonics technology and Aston’s long experience in WDM systems R&D provides an ideal platform for this industry/academia research partnership. Together, we have a compelling vision, and I am particularly delighted by the prospect of collaborating with the innovators at EFFECT Photonics, and experiencing the energy, drive and ambition of its start-up working culture.” – Prof. Wladek Forysiak.
EFFECT Photonics’ programmable System-on-Chip technology lies at the heart of its developments in coherent optics. The aim is to provide products that offer line card performance and functions in a pluggable form factor with a very high energy efficiency. This means that performance that has historically been big and expensive, will be pushed to the edges of the network including the encryption and data security you would normally expect to find in a line card. In addition, by lowering the cost and energy consumption per bit, the next generation EFFECT Photonics solutions will enable a more sustainable and greener optical network.
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D, manufacturing in South West UK and a facility opening soon in the US, with sales partners worldwide.
http://www.effectphotonics.com
Press contact: press@effectphotonics.com

EFFECT Photonics to open facility in the US
EFFECT Photonics is pleased to announce that it is taking an exciting next step forward…
EFFECT Photonics is pleased to announce that it is taking an exciting next step forward by opening a facility in the US. As part of the growth strategy, this is a logical next step to further deepen the commitment to customers and partners in the whole of the Americas region. At the same time, this will also allow EFFECT Photonics to better support European and Asian based customers with operations in the region.
The US-based team will be a customer focused expansion of the engineering, product testing & verification, customer support and marketing capacity to complement the European teams. In addition, the new facility will also be designed to include an application lab and demo center which will be leveraged to ensure that the current products are designed and deliver to meet the needs of the customers, and to get insights for the next generation of highly integrated, low cost optical solutions. The regional team will be better placed for quicker customer response times and to provide greater agility in supporting the pre and post sales efforts.
“Photonics is a global industry and we have the goal to be a global company. We are a fast growing organisation, offering compelling and innovative integrated photonic solutions. Expanding our geographic presence beyond The Netherlands, the UK and Taiwan, offers us the opportunity to be at the heart of one of our largest markets and to be closer to our customers and partners in the region.” – James Regan, CEO
The facility is due to be operational in Q4 of 2021 and will be located in the greater Boston area. This is an ideal location to augment the resources EFFECT Photonics already has on the West Coast. It offers an easy bridge to Europe for time-zone management and fast, seamless collaboration. Technology is a key industry in the area, offering the opportunity to build out the team with highly skilled and experienced technical talent, as well as tapping into a pool of future talent because of the great universities and colleges. And because of the presence of the research university and a number of leading teaching hospitals, there is a long history of taking IP from labs to market, something that is core to the EFFECT Photonics philosophy.
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers.
http://www.effectphotonics.com
Tags: America, Boston, Integrated Photonics, photonic integration, US
EFFECT Photonics appoints Pangaea (H.K.) Limited as key distributor in Asia
EFFECT Photonics is pleased to announce that it has appointed Pangaea (H.K.) Limited (Stock Code:…
EFFECT Photonics is pleased to announce that it has appointed Pangaea (H.K.) Limited (Stock Code: 1473.HK) as a distributor for China, Taiwan and Southeast Asia. The collaboration between the two companies will create great synergistic effect on business development in the region. With more than 30 years’ experience in the telecom industry, Pangaea will offer the EFFECT Photonics optical tunable solutions in pluggable format from 10Gb/s and above.
“This is a great step in furthering our partnership with Pangaea. We value their deep experience in optical communications and their strong presence in the region. We know that they will provide great sales and application support to their 5G, optical network and data centre customers.”, says Harald Graber, Chief Commercial Officer at EFFECT Photonics.
“We have strong belief in the outstanding technology of EFFECT. The teamwork with EFFECT will bring up one of the best products to support our customers in their 5G and optical network developments. We are excited to see more product choices and benefits to come from this partnership.”, says Richard Fung, CEO & President at Pangaea.
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide.
http://www.effectphotonics.com
About Pangaea
Founded in 1990, Pangaea plays an important role in the supply chain of the telecom and datacom connectivity industry and serves as a channel partner of our suppliers and a co-design partner of our customers. Pangaea helps our customers to design and build custom solutions, offer a diverse portfolio of innovative network connectivity products and provide complementary value-added services, which improve efficiency, enhance performance and drive down costs. The scope of Pangaea’s services includes collaborating with our customers to provide : (i) specified sourcing and selection of components; (ii) solution development and product application design; (iii) bridging for the access of technologies between suppliers and customers; (iv) lab testing, design and verification; (v) supporting for next generation product development; (vi) technical knowhow and talent to achieve customers’ design at the optimal performance and reliability levels and satisfaction; and (vii) pre-and post-sales services and follow up.
http://www.pangaea.com.hk
Tags: 5G, optical network, optical transceivers, Pangaea, tunable transceivers

EFFECT Photonics awarded funding from Heart of South West grant scheme
EFFECT Photonics is honoured to be one of two companies in the UK recently awarded…
EFFECT Photonics is honoured to be one of two companies in the UK recently awarded funding from the Heart of South West LEP ERDF Inward Investment Support Grant Scheme. The fund is designed to boost economic recovery and create new job opportunities in Devon, Somerset, Plymouth and Torbay.
EFFECT Photonics has R&D and manufacturing facilities in the region and the additional funding will be used for further expansion to the production facilities, creating at least 70 new jobs. EFFECT Photonics COO, Paul Rosser, said: “This investment comes at a crucial time, enabling us to grow the team in Devon, build capacity to service increasing demand and continue to innovate. We are entering an exciting period, bringing a genuinely value-adding product to a sector that is seeing huge growth as the rollout of 5G accelerates.”
Click here to read the full press release.
Tags: CoherentPIC, Investment, InvestNL, Photonics, Telecom
EFFECT Photonics completes its Series-C funding round raising a total of $43M
Today EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components…
Today EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based on its optical System-on-Chip technology, announces the completion of its Series-C funding round, with an additional $6M from the Dutch impact investor Invest-NL, raising a total of $43M.
The first close of the investment round, was co-led by Smile Invest together with existing investor Innovation Industries Fund, exactly one year after announcing the tape-out of its Manta full photonic integration coherent PIC. Smile Invest are joined by existing investors including Innovation Industries Fund, Photon Delta, btov Partners, Brabant Development Agency (BOM) and individual investors. This new round of funding will be used to further expand the current product line of optical transceivers for among other things 5G networks, and to scale up production capacity. In addition, the R&D activities for the next generation of optical chips, with capacity of more than 400 gigabits per second, will also be ramped up.
(Integrated) photonics is a chip technology in which light signals (photons) are used instead of electrical signals (electrons). In a photonic chip, light signals can be generated, modulated, filtered, and detected. The chip technology developed in Eindhoven is the only photonics technology in which all these functions are combined on a single chip, which replaces a complete optical system. These photonic chips currently allow for high-speed data transfer over fiber optic networks, but the technology can also be used in highly sensitive measuring systems in the medical, automotive and the agri-food industries. It is expected that future quantum computers will also use photonic chips on a large scale.
EFFECT Photonics is a spin-off from the Eindhoven University of Technology. As a pioneer in the field, it is one of the first companies to successfully bring a product on the market based on the photonics technology developed at the university. The demand for internet bandwidth by end-users is growing exponentially every year. A trend that is being further accelerated by primarily by the roll-out of 5G, and the increase in working from home due to the Corona virus. EFFECT Photonics enables network operators to increase the capacity of their existing infrastructure without having to lay addition cables which is very costly. Upgrading the transceivers is therefore a more cost-efficient solution in address this need for additional bandwidth.
Boudewijn Docter, one of the founders and President of EFFECT Photonics: “As a company, we have come a long way to make the photonics technology market-ready. We are pleased that Invest-NL is joining our other investors in helping us scale up our production and enabling us to bring additional products to market quicker”.
Ruud Zandvliet, Senior Investment Manager at Invest-NL: “The Netherlands has a unique ecosystem for photonics technologies. EFFECT Photonics is a leading player in this field, capable of developing complex, fully integrated photonic chips. This offers the company the opportunity be a leading player as a manufacturer of the next generation of transceivers. By joining this investment round, Invest-NL contributes to the availability of financing for upscaling and future R&D investments. This is a good example of the role Invest-NL plays in increasing the strength of scale-ups and is in line with our objective of making the Netherlands more sustainable and innovative.
— End of Press Release —
About EFFECT Photonics
EFFECT Photonics produces components for fiber optic networks based on photonic chip technology, originally developed at Eindhoven University of Technology. The unique chip technology from EFFECT Photonics delivers high communication speeds for low costs and low energy consumption. EFFECT Photonics products are used to connect mobile network transmitters to the rest of the Internet and to connect data centers. With the technology of EFFECT Photonics, the capacity of existing fiber optic networks can be increased without having to install additional cables. EFFECT Photonics has offices in Eindhoven Netherlands, Great Britain and Taiwan and an international network of sales partners. www.effectphotonics.com
Contact EFFECT Photonics: press@effectphotonics.com • +31 403041359
About Invest-NL
Invest-NL is an impact investor committed to businesses and projects that will make the Netherlands more sustainable and innovative. Its focus lies on carbon-neutral and circular economy and on innovative, fast-growing companies, or scale-ups. Invest-NL supports innovative entrepreneurs through financing and advice according to one simple principle: impact is our goal, return is our means. As the Dutch partner for European investment institutions, Invest-NL is dedicated to cooperation and always works together with other investors. Invest-NL is headquartered in Amsterdam and employs a staff of 60 people. For more information, go to https://www.invest-nl.nl.
Contact Invest-NL: • Paul Hartogsveld: press@invest-nl.nl • +31 611589127
Tags: CoherentPIC, Investment, InvestNL, Photonics, Telecom
5G Hub has Dutch first: EFFECT Photonics and Vodafone start testing optical SoCs in 5G mobile network
Vodafone first telecom provider in the Netherlands to test this technology on mobile network Eindhoven…
Vodafone first telecom provider in the Netherlands to test this technology on mobile network
Eindhoven – April 15, 2021 – Earlier this week, during a visit by NLdigital, the industry association of the digital sector, the 5G Hub in Eindhoven announced a first in the Netherlands: EFFECT Photonics and Vodafone have started testing the integration of so-called optical SoCs in the mobile network. This optical ‘System-on-Chip’ technology is expected to offer internet providers and users many advantages in the future. This includes less delay, higher capacity, but also improved network sustainability. These chips reduce the need for hardware and will significantly reduce both energy consumption and maintenance costs. Vodafone is the first telecom provider in the Netherlands to test this technology in the current network.
“Photonics play a key role in the sustainable digital future of the Netherlands. I am proud that as a sector we are at the forefront of the development and application of this new technology”, says Lotte de Bruijn, Managing Director at NLdigital.
Photonics: the heart of the internet of the future
In almost all current electronic networks, electrons do the work – electrical signals bring data from A to B. In this type of electronic hardware there are often system-on-chips (SoCs): entire computer systems on a single chip. For example, the heart of a smartphone also contains such a SoC. The technology behind “normal” chips, although further developed over the years, is already more than 30 years old. A trend that will grow exponentially in the coming years is a greater need for more network capacity and less delay. In order to meet this, the relatively new optical SoCs are a possible solution: these chips transmit and process data based on light signals via laser. This improves the performance of the mobile network, while requiring less energy.
“The first results of the tests are positive,” said Boudewijn Docter, President at EFFECT Photonics. “A working link has been established in the lab with all filters and other components that are also present in a real connection. The next step is testing in the field. This is an important step to show that the EFFECT Photonics SoC technology, for minimal investment, can help to upgrade the capacity of the existing networks. And it is also this SoC technology that has been created in collaboration with our eco-system partners PhotonDelta and Brainport. It is great to see that this technology is now actually used in the Netherlands and that it is also a first for our home base Eindhoven.”
“The Netherlands has strong networks, the best in Europe, and we would like to keep it that way. That is why we are constantly innovating to improve our network, including this implementation of the photonic chip technology in the network of the 5G Hub,” says Bram Tijdhof, Director Regulatory, Policy and Public Affairs at VodafoneZiggo. “Photonics is one of the key technologies in the Netherlands and also of Dutch origin. We should be proud of that. The collaboration with the photonics cluster on the High Tech Campus with the 5G Hub makes this first extra special.”
5G Hub: a hotbed of innovation
The 5G Hub is a collaboration with Brainport Development, Ericsson, High Tech Campus and Vodafone to drive results around certain social challenges. It is intended as a breeding ground for new 5G technology. The space on the High Tech Campus has more than 700m2 and is close to tech giants such as ASML, Philips, TNO and TomTom. The expectation is that in the coming years numerous new ideas and applications will emerge from here in the field of 5G and other technologies, such as photonics, blockchain and machine learning. To further enable this, radio technology has been installed in the Hub to be able to apply it to 5G. It is suitable for the 3.5 gigahertz test frequency and offers very high speed and ultra-short response times. For maximum capacity, this can be combined with existing 4G frequency bands 800, 1800, 2100 and 2600 megahertz which are also available in the Hub. This allows companies to take their 5G innovations from idea and research, to real life results.
Click here for an article which provides a deeper dive into integrated photonics and 5G.
For more information and/or questions as a result of this press release, please contact the following spokespersons/contacts as a journalist:
About EFFECT Photonics
EFFECT Photonics produces components for fiber optic networks based on photonic chip technology, originally developed at EINDHOVEN University of Technology. The unique chip technology from EFFECT Photonics delivers high communication speeds for low costs and low energy consumption. EFFECT Photonics products are used to connect mobile network transmitters to the rest of the Internet and to connect data centers. With the technology of EFFECT Photonics, the capacity of existing fiber optic networks can be increased without having to install additional cables. EFFECT Photonics has offices in Eindhoven Netherlands, Great Britain and Taiwan and an international network of sales partners.
For more information, go to www.effectphotonics.com t: +31 403041359 press@effectphotonics.com
About Vodafone
Vodafone Nederland is the second largest mobile telecommunications company in the Netherlands based on turnover and profitability and has more than 5 million customers as of 31 December 2020. The offices are located in Utrecht, Eindhoven and Maastricht. Vodafone Nederland is part of VodafoneZiggo, a 50/50 joint venture between Vodafone Group and Liberty Global. Vodafone Group is one of the world’s largest mobile telecommunications companies in revenue, with more than 300 million mobile customers, 27 million fixed broadband customers, more than 22 million TV customers and connecting more than 108 million IoT devices, since December 31, 2020. Vodafone has mobile networks in 22 countries and works with 48 mobile networks worldwide.
For more information, go to www.vodafoneziggo.nl t: +31 (0)88-7170717 m: pers@vodafoneziggo.com
- Letícia Batista, 5G Hub, info@5ghub.nl
- Sylvia van Haren, Ericsson, M: 06 5519 6600 or sylvia.van.haren@ericsson.com
- Annemiek Bles, Brainport Development, M 06 4157 6715 or a.bles@brainportdevelopment.nl
- Hilde de Vocht, High Tech Campus, M 06 5317 9026 or hilde.de.vocht@hightechcampus.com


The Post-Brexit Landscape: Photonics Perspectives
EFFECT Photonics’s CEO, James Regan, was delighted to speak to Optics and Photonics News Magazine…
EFFECT Photonics’s CEO, James Regan, was delighted to speak to Optics and Photonics News Magazine on an article about: The Post-Brexit Landscape: Photonics Perspectives.
On 24 December 2020, almost literally at the last minute, and more than four years after the United Kingdom voted to leave the European Union, the U.K. and the EU finally sealed a trade and cooperation agreement to govern their post-Brexit relationship. The agreement’s stakes were high; in 2019, some 43% of Britain’s exports of goods and services went to the EU.
For a while, the final months of negotiation on a new framework to govern that big chunk of trade seemed impossibly snagged on arcane details of fishing rights in U.K. waters and state aid to industries. In the end, though, the December accord—which guarantees tariff-free trade in most goods between the U.K. and the EU—led to deep breaths and a sense of relief on both sides of the Channel.
The immediate aftermath of the agreement, which came into force 1 January 2021, included some well-reported delays and snarl-ups for imports and exports of trade goods, as businesses attempted to grapple with a suddenly “hard” U.K.–EU border and new paperwork requirements. But now, three months in, much of that dust has settled. To get some insight on the accord’s impact for photonics—and, particularly, on the U.K.’s future participation in the new framework program for EU research funding, Horizon Europe—OPN recently talked with several members of the European photonics community.
Politics and reality
Notwithstanding the eleventh-hour post-Brexit agreement in December 2020, one could be forgiven for thinking that relations between the U.K. and the EU have reached something of a low point in the past several months. Tensions have especially flared over the availability of COVID-19 vaccines, and over the complex post-Brexit status of Northern Ireland. There was even an announcement, in February, that a Cold War-style “emergency hotline” would be set up between Brussels and London to handle post-Brexit tensions.
Yet in the wake of the December agreement, these political twists and turns might prove relatively unimportant to the real-world photonics business.
James Regan, EFFECT Photonics CEO explains: “I think it’s important to pick apart government posturing from teams of people actually working on the ground,” says James Regan, the CEO of the Eindhoven, Netherlands–based company EFFECT Photonics, which develops and manufactures on-chip modules for the communications market. “Our governments do what our governments do, but where there are long-standing relationships, those are largely not affected by that … Business is done between people, not between governments.”
A sense of relief
Regan is particularly well positioned to see both sides of the post-Brexit agreement. While headquartered in Eindhoven, EFFECT Photonics also operates a development lab and manufacturing facility in Brixham, Devon, U.K. (The company has a unit in Taiwan as well, and Regan expects that it will branch into other world regions in the future.) From that broad perspective, he says that one of the biggest benefits of the deal is simply putting an end to more than four years of uncertainty since the 2016 Brexit vote.
“It was very frustrating,” Regan observes. “Like all of business, what we wanted was to have clarity … Nobody likes the inability to plan.” Another frustration, he adds, was that “people will often tend to assume the worst-case scenarios,” an orientation that Regan believes can distract from important issues. “At least now we have clarity,” he says. “We understand what the situation is, and we go forward and build around the landscape that we find.”
Continue reading the entire article: https://www.osa-opn.org/home/newsroom/2021/march/the_post-brexit_landscape_photonics_perspectives/

– About EFFECT Photonics –
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
For more on our technology, visit: https://effectphotonics.com/technology/

EFFECT Photonics WINNER at Tech Tour Future21
EINDHOVEN, The Netherlands – March 29, 2021 – EFFECT Photonics, a leading developer of high-performance…
EINDHOVEN, The Netherlands – March 29, 2021 – EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based on its optical System-on-Chip technology, is pleased to announce that it has been selected as top of the top at Tech Tour 2020 Programmes and is one of the top winners at Tech Tour Future21. Tech Tour is one of largest investor-oriented communities in Europe connecting entrepreneurs, investors, and corporate partners from across the world.
The event:
- Took place from 24 – 26 March 2021, online.
- More than 500 investors.
- EFFECT Photonics has been selected as top of the top among 1,000 tech entrepreneurs over multiple sessions.
- Tech Tour Future21 winners:
- EFFECT Photonics – James Regan
- Aistech Space – Sofia Aldape Flom
- AIXaTech GmbH – Volker Sinhoff
- Astrocast – Fabien Jordan
- Augmented Robotics – Tony Nitschke
- Avantama AG – Samuel Halim
- CtrlMovie – Tobias Weber-Ingold
- mailo Versicherung AG – Dr. Matthias Uebing
- nyris GmbH – Dr. Anna Lukasson-Herzig
- RAUM virtual reality collaboration – Michael Gairing
- Swiss Vault – Bhupinder Bhullar
- troy gmbh – Philip Rürup
- Valispace – Marco Witzmann
– About EFFECT Photonics –
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
For more on our technology, visit: https://effectphotonics.com/technology/
Get in touch with us for further information by sending your request to: sales@effectphotonics.com
– About tech Tour –
Tech Tour Tech Tour is committed to the development of emerging technology companies in Europe and has been doing it for 20 years. The Tech Tour Community is made up of innovative investors, high tech entrepreneurs (from early to late-stage), corporate and government influencers that want to drive European innovation further. https://techtour.com/


EFFECT Photonics works together with TU Delft and partners to create superhighway for digital data
Eindhoven, March 2021 – EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing…
Eindhoven, March 2021 – EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based on its optical System-on-Chip technology, collaborates with TU Delft researchers and 20 more partners to develop reliable and safe wireless broadband connections using light instead of radio waves.
Superhighway for digital data
Optical Wireless Superhighways: Free photons (at home and in space): FREE
Information is the lifeblood of today’s digital society. The amount of data, and the use of that data, has increased exponentially over the last 50 years. However, traditional technologies used to distribute data, from Wi-Fi in our homes to satellite communications, have already reached or will soon be reaching their limit in terms of capacity. There is a growing need for a new and unifying paradigm for wireless connectivity. As part of the FREE consortium, 21 partners have joined forces to develop new solutions that use light instead of radio waves (which is what the 5G network is based on, for example) to create reliable and secure wireless broadband connections.
The consortium will develop the technology that ultimately may enable a ‘network of networks’, in which satellite communications are seamlessly integrated with ground-based networks to provide satellite-to-satellite Network Functions Virtualisation (NFV) and Software Defined Networking (SDN). This simplified integration between terrestrial and satellite networks will open up new opportunities for the Internet of Things (IOT), as well as for more accurate weather forecasting, for example. The consortium anticipates that the huge amount of available bandwidth, the inherent security, the limited latency and license-free operation will result in a 10- to 100-fold increase in wireless connectivity.
Prof. Dr. Henri Werij, Dean of the Faculty of Aerospace Engineering at TU Delft, explains in a video how this technology will allow to securely send and process digital data at high speeds, with low latency.
Programme leader: Prof. Dr. Eberhard Gill (TU Delft)
Consortium partners: Airbus DS, Aircision, Demcon, EFFECT Photonics, Flexible, Hyperion Technologies, ISIS, Lionix, NLR, Phix, Quix, Signify, Single Quantum, S&T, TU Delft, Eindhoven University of Technology, TNO, Leiden University, Twente University, Vrije Universiteit Amsterdam, VTEC
Article source: https://www.tudelft.nl/en/2021/tu-delft/tu-delft-and-partners-to-create-superhighway-for-digital-data
– About EFFECT Photonics –
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com


EFFECT Photonics raises $37M to develop single-chip coherent optics and scale production
Today EFFECT Photonics announces the first close of its Series C round, co-led by Smile…
Today EFFECT Photonics announces the first close of its Series C round, co-led by Smile Invest together with existing investor Innovation Industries Fund, exactly one year after announcing the tape-out of its Manta full photonic integration coherent PIC. Smile Invest are joined by existing investors including Innovation Industries Fund, Photon Delta, btov Partners, Brabant Development Agency (BOM) and individual investors.
EFFECT Photonics is a world leading developer of optical transceivers, bringing core network performance to the network edge, through integration of all the optical functions on to a single Photonic Integrated Circuit combined with low cost, non-hermetic packaging.
James Regan, CEO stated: “With our disruptive technology, we have already enabled DWDM in high-capacity 5G Radio Access Networks through our low-cost autotuning SFP+ modules, which are deployed around the world. This funding and our partnership with our investors will allow us to take the next leap forward, bringing even higher capacity “coherent” products to the network edges, as well as scaling existing production.”
Tim Koene, CTO explained: “Conventional coherent approaches require external narrow-linewidth tunable lasers and amplification, wasting light and adding cost, space and power consumption. Already demonstrated to key customers, the non-hermetic Manta prototypes integrate all of these functions on a single chip, bringing a revolution in low electrical power consumption together with high optical output power: high transmission performance in a small formfactor that will enable the next generation of edge network capacity.”
Bart Cauberghe, Managing Partner at Smile Invest commented: “We see in EFFECT Photonics a company with unique technology, with a team that has shown that they can also convert this into innovative products for a fast-growing market. In that respect, the company fits perfectly in the activities of Smile Invest, given our focus on innovative, ambitious companies that have the potential to become the market leader in their segment. We are delighted to be joining with the strong group of existing investors”.
Nard Sintenie, General Partner at existing investor Innovation Industries added: “What EFFECT Photonics has developed is a real platform technology, with which new products can rapidly be launched. We are pleased to continue to support the company and see great potential for the future”.
— End of Press Release–
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
Contact us: • press@effectphotonic.com • +31 403041359
About Smile Invest
Smile Invest (Smart Money for Innovation Leaders) is a European evergreen investment firm with €350 million assets under management, financed by 40 entrepreneurial families and with a long term focus on innovative growth companies. Smile Invest focuses on companies active in technology, healthcare and innovative consumer markets. From its offices in Leuven and The Hague the team supports ambitious entrepreneurs and management teams in realising their growth plans. www.smile-invest.com
Contact Smile Invest: Bart Cauberghe, Managing Partner • bart.cauberghe@smile-invest.com • +32 476 33 66 69
Tags: EFFECT Photonics, Funding, Hightech, IntergratedPhotonics, Investment, Optical Chips, PIC
NASA acknowledges EFFECT Photonics’ PIC as a State-of-Art commercial example
Eindhoven – February 10, 2021 – NASA’s Jet Propulsion Laboratory lists EFFECT Photonics and its…
Eindhoven – February 10, 2021 – NASA’s Jet Propulsion Laboratory lists EFFECT Photonics and its powerful monolithically integrated PIC (Photonic Integrated Circuit) DWDM optical transceiver chip, as an example of State-of-Art commercial PIC. Packaging PIC’s for space applications remains a challenge. EFFECT Photonics has specially developed non-hermetic packaging solution, which can be used to replace traditional ”gold-box” packaging solutions. According to NASA optical communications is the future of space communications and the driving force is the requirement for more bandwidth, which is available only using optical solutions such as free-space laser links in both inter-satellite and satellite-to-ground communications.

EFFECT Photonics’ System-on-Chip (SoC)
EFFECT Photonics is the first company in the world to introduce a full optical SoC – combining all the optical elements needed for optical networking onto a single die.
One key application of EFFECT Photonics’ SoC technology is within dense wavelength division multiplexing (DWDM), and this is regarded as an important innovation in optical networks. DWDM is scalable, transparent and enables provision of high-bandwidth services. It is the technology of choice for many networking applications today. By using many different wavelengths of light to route data, these systems are more efficient, flexible, and cost-effective to build, own and operate compared to single-channel, point-to-point links. Thanks to our high-density electrical interconnect and packaging technology, the optical system-on-a-chip can be assembled for volume manufacture at low cost.
As the channel count increases, the physical space in which the equipment is housed gets larger and the power consumption increases as well. The key enablers for DWDM systems at the edge of the network are photonic integration of components within a single chip; and the ability to produce these in volume with high yield at low cost. This requires a change in the way indium phosphide (InP) chips are designed, tested, and packaged, which is where EFFECT Photonics comes in.
For further information about our products and technologies please visit our website www.effectphotonics.com or contact sales@effectphotonics.com
– About EFFECT Photonics –
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
Tags: EFFECT Photonics, NASA, Photonics, PIC, Telecom, Transceivers
EFFECT Photonics joins the Telecom Infra Project and its Open Optical & Packet Transport Project Group
EFFECT Photonics has joined the Telecom Infra Project (TIP), a global community of companies and…
EFFECT Photonics has joined the Telecom Infra Project (TIP), a global community of companies and organizations that are driving infrastructure solutions to advance global connectivity.
TIP was founded in 2016 and consists of a diverse range of companies including service providers, technology partners, systems integrators and other connectivity stakeholders. TIP’s members work together to develop, test and deploy open, disaggregated, and standards-based solutions providing the high-quality connectivity the world needs now and in the future.
EFFECT Photonics is a member of TIP’s Open Optical & Packet Transport Project Group, which is working on defining open technologies, architectures and interfaces used in Optical and IP Networking. The group is involved in developing different parts of the Transport network architecture including optical transponders, line systems, IP access devices, open API’s and network simulation and planning tools.
EFFECT Photonics’ CCO Harald Graber explains: “The networking industry is evolving at a constantly growing pace while now, more than ever before, high bandwidth access for everybody is needed. This is achievable only through open collaboration. TIP is addressing these questions and shares so many EFFECT Photonics’ values that we are more than excited to join and contribute to TIP’s vision. Our unique optical SoC technology and packaging competence can contribute to achieving the TIP community’s goals. Furthermore, our NarroWave technology and optimized transceivers for the 5G-XHaul environment can support TIP’s OpenRAN initiative. We are excited to see what our end customers are able to do with the products we have developed.”
EFFECT Photonics’ product portfolio includes the currently shipped 10Gbps 40km DWDM Narrow Tunable SFP+ module which has industrial temperature range and low power consumption compared to competing designs. It is also available with the optional NarroWave functionality with auto-tune and remote digital diagnostics which make these devices an attractive choice for network operators looking to add bandwidth without adding physical fibre while saving on deployment and installation costs by allowing remote monitoring and control.
– End of Press Release –
About the Telecom Infra Project
The Telecom Infra Project (TIP) is a global community of companies and organizations that are driving infrastructure solutions to advance global connectivity. Half of the world’s population is still not connected to the internet, and for those who are, connectivity is often insufficient. This limits access to the multitude of consumer and commercial benefits provided by the internet, thereby impacting GDP growth globally. However, a lack of flexibility in the current solutions – exacerbated by a limited choice in technology providers – makes it challenging for operators to efficiently build and upgrade networks. Founded in 2016, TIP is a community of diverse members that includes hundreds of companies – from service providers and technology partners, to systems integrators and other connectivity stakeholders. We are working together to develop, test and deploy open, disaggregated, and standards-based solutions that deliver the high- quality connectivity that the world needs – now and in the decades to come. Find out more: www.telecominfraproject.com
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
For further information please contact press@effectphotonics.com


EFFECT Photonics winner in the Deep Tech Programme 2020!
EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based…
EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based on its optical System-on-Chip technology, is one of the winners in the Deep Tech Programme 2020 -Tech Tour.
EFFECT Photonics was one of the 50 selected companies to present at the TechTour Deep Tech Programme 2020 (https://techtour.com) on November 24, 26 and 27. Presenting companies were reviewed by an expert jury of VCs and corporate investors.
As one of the best-scored winners, EFFECT Photonics will get a chance to participate in the World Tour where all winners of different Tech Tour Programmes will be invited to additional sessions with investors from Europe, the United States, and Western Africa. The World Tour will take place in March 2021.
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
For further information please contact sales@effectphotonics.com
Tags: Deep Tech, EFFECT Photonics, Photonics, transceiversSFP
EFFECT Photonics establishes New Product Development department in EPIC Centre
Having already based its production facilities in Brixham, Dutch optical communications specialist EFFECT Photonics has…
Having already based its production facilities in Brixham, Dutch optical communications specialist EFFECT Photonics has broadened its local presence by occupying two units at EPIC – the renowned innovation center in Paignton. The facility’s modern lab and offices will help in developing the company’s manufacturing and engineering activities.
Existing tenants of the Electronics and Photonics Innovation Centre (EPIC), which is dedicated to photonics and electronics, include a number of multinationals in this field. It provides various services to support their technological innovation and encourages collaboration between businesses and research institutions.
The new tenant at EPIC leverages photonic integration to deliver unlimited data transmission capacity and internet bandwidth to everybody, everywhere, and through every available device. Its latest optical transceiver technologies are expected to sustain the rollout of 5G mobile networks.
In 2015, those technological advances led EFFECT Photonics to Brixham, to set up production in a highly tech-focused environment. The Torbay area has attracted tech talent from near and far, and it’s no wonder that today people refer to it as the ‘Silicon Valley of the South West of England’.
“We had previously enjoyed various positive interactions with EPIC over the years and it made good business sense to explore how we could intensify this contact. The move will allow us now to begin using state-of-the-art assembly equipment,” explains Andrew Stimson, Operations Project Manager at EFFECT Photonics.
“We strongly feel EPIC has the ideal environment to develop the foundations for packaging our next-generation products. Besides our lab and offices, we benefit from EPIC’s equipment and services, including a clean room and various meeting rooms. We already have working relations with two other EPIC tenants, Bay Photonics and Davies and Bell. It’s both challenging and rewarding to co-operate with other photonics specialists to enhance our own fast, affordable, sustainable and effective communication technologies.”
The move to EPIC should also generate new job opportunities, building on campaigns already in place to find tech talent for company locations in Eindhoven and Brixham.
– About EFFECT Photonics –
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
– About the Electronic and Photonics Innovation Centre (EPIC) –
EPIC is a centre of excellence, supporting technological innovation and promoting collaborative activity between businesses and research institutions. It focuses on supporting high potential companies and encourages investment into Torbay’s microelectronics and photonics sector, and in the wider Heart of the South West. EPIC is managed by TDA, a trading name of Torbay Economic Development Company Limited. As a Centre of Excellence, EPIC will provide the ideal environment for both small and large technology companies within the sector. The Centre will provide opportunities for collaboration, R&D, design, new product development. The facility has established links with academia and research institutes, and other European clusters as well as looking to develop global partnerships. For more information, visit: https://epic-centre.co.uk/
Tags: Brixham, EFFECT Photonics, EPIC, TDA, Torbay
EFFECT Photonics: A Proud Member Of EPIC
Eindhoven, Oct 29, 2020 – EFFECT Photonics is a corporate member of the European Photonics…
Eindhoven, Oct 29, 2020 – EFFECT Photonics is a corporate member of the European Photonics Industry Consortium (EPIC), the industry association that promotes the sustainable development of organizations working in the field of photonics in Europe. EPIC fosters a vibrant photonics ecosystem by maintaining a strong network and acting as a catalyst and facilitator for technological and commercial advancement. EPIC publishes market and technology reports, organizes technical workshops and B2B roundtables, supports EU funding proposals, advocacy and lobbying, education and training activities, standards and roadmaps, pavilions at exhibitions. www.epic-assoc.com
Together with other members from the photonics related technologies, we at EFFECT Photonics are committed to actively contribute to the technological and commercial advancement of the integrated photonics industry globally. EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
This partnership is a significant addition to the already impressive member list of EPIC of more than 600 companies in 35 countries: https://www.epic-assoc.com/membership/epic-members/


EFFECT Photonics one of Europe’s 40 top high-tech startups to High Tech Venture Days (HTVD) 2020
EINDHOVEN – September 2020 – EFFECT Photonics, a leading developer of high-performance dense wavelength division…
EINDHOVEN – September 2020 – EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based on its optical System-on-Chip technology, has been selected as one of Europe’s 40 top high-tech startups to pitch at the High Tech Venture Days (HTVD) 2020. HTVD is one of Europe’s leading meeting places for tech companies, international investors and corporates and is launching on October 13-14 in Dresden, Germany.
Our CEO, James Regan, will be taking the stage at pitches and panel discussions and will give insight into the EFFECT Photonics’ unique integrated photonics technology. EFFECT Photonics is the first company in the world to introduce a full optical system-on-chip (SoC) – combining all the optical elements needed for optical networking onto a single die. One key application of EFFECT Photonics’ SoC technology is within dense wavelength division multiplexing (DWDM), and this is regarded as an important innovation in optical networks. DWDM is scalable, transparent and enables provision of high-bandwidth services. It is the technology of choice for many networking applications today. By using many different wavelengths of light to route data, these systems are more efficient, flexible, and cost-effective to build, own and operate compared to single-channel, point-to-point links. Thanks to our high-density electrical interconnect and packaging technology, the optical system-on-a-chip can be assembled for volume manufacture at low cost.
Let us talk at HTVD20, we will show how EFFECT Photonics will revolutionize the integrated photonics market with our Optical SoC technology.
For more on our technology, visit: https://effectphotonics.com/technology/
Get in touch with us for further information by sending your request to: sales@effectphotonics.com
Tags: DWDM, Hightech, HTVD, Photonics
EFFECT Photonics secures additional funds to accelerate its growth
On Friday 7 August, EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing…
On Friday 7 August, EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based on its optical System-on-Chip technology, completed its Series-B funding with an additional 8 million Euro. The investment round, led by independent venture capital fund Innovation Industries, secured continued participation from btov partners, Innovatiefonds Brabant BV, Beek Capital and Optiverder BV, and attracted PhotonDelta as a new partner.
The superiority of EFFECT Photonics’ technologies in the key growth market of integrated photonics has been a major factor in attracting diverse investors who see the unique value of the company and its impact on the industry. According to the company, making photonics applications universally accessible, affordable, and sustainable calls for the development of long-lasting partnerships that promote the sharing of knowledge and experience.
Sophie De Maesschalck, CFO at EFFECT Photonics, comments: “This investment will not only support EFFECT Photonics by accelerating the sales and marketing effort, but will enable further improvement in time-to-market for our range of optical communication products, and in particular those developed for the 5G network.”
Nard Sintenie, a partner at Innovation Industries, says: “We continue to support EFFECT Photonics because we firmly believe in the strength of the technology in the short term, as well as its disruptive impact in the longer term, and we see an organisation that is capable of delivering on that promise.”
Ewit Roos, CEO of PhotonDelta, adds: “EFFECT Photonics has always been an important partner for PhotonDelta. They are a frontrunner in the development of complex integrated optical products in a high-volume market. Since their products are supported by many other companies within the integrated photonic scene, we believe that consistently supporting this partner’s growth ambitions will have a positive effect on the entire supply chain of integrated photonics in the Netherlands.”
– End of press release –
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low-cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacentres and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
Contact us:
EFFECT Photonics B.V.
Tel: +31 40 3041359
press@effectphotonics.com

EFFECT Photonics and TEGEMA are awarded for their role in the development of integrated photonics
Great achievement for EFFECT Photonics and TEGEMA!! On Monday, July 20, the 21 municipalities of…
Great achievement for EFFECT Photonics and TEGEMA!!
On Monday, July 20, the 21 municipalities of the Eindhoven Metropolitan Region (MRE) in the Netherlands awarded EFFECT Photonics and TEGEMA and for the important role both companies play in the development of integrated photonics. In the photo, Directors Pierre van Lamsweerde (Tegema) and Tim Koene (EFFECT Photonics) received the award of 50,000 euros from Jan Boersma of the municipality of Son and Breugel.
Full article in Dutch here: https://www.nu.nl/eindhoven/6065628/metropoolregio-overhandigt-twee-fotonicabedrijven-cheque-van-50000-euro.html
For more about our photonics technologies, visit: https://effectphotonics.com/technology/ultra-pure-light-sources/
Get in touch with us for further information by sending your request to: sales@effectphotonics.com


Join us at OFC 2020
From March 10 to 12 2020, EFFECT Photonics will be exhibiting at the OFC (Optical…
From March 10 to 12 2020, EFFECT Photonics will be exhibiting at the OFC (Optical Networking and Communication Conference & Exhibition) in San Diego, California, USA. OFC is the largest optical communications conference in the world. Representing a range of products, from optical components and devices to systems, test equipment, software and specialty fibre, OFC represents the entire supply chain and provides the premier marketplace where the industry learns, connects, networks and closes deals.
Interested in what EFFECT Photonics is working on right now? We are exhibiting at booth #6012 and will be showing:
Energy-efficient Tunable SFP+ Transceivers for Next Generation Mobile Networks (Live Demo)
EFFECT Photonics is demonstrating it’s new energy-efficient tunable SFP+ transceiver. Optical transceivers equipped with our latest System-on-Chip (SoC) technology consume less than 1.5W of power at 85C. This opens up the use of these transceivers in legacy systems that were previously designed for Class II fixed wavelength devices, allowing our customers more flexibility in the field without changing their installed base. Furthermore, future systems for Mobile Fronthaul, such as the smaller cells required for 5G, are designed to be unobtrusive and smaller, while requiring more transceivers because of the increased capacity. These two requirements together create the need for an energy-efficient transceiver with low power dissipation. This is what the latest addition to EFFECT’s product portfolio provides.
NarroWave enabled SFP+ modules
At OFC 2020 EFFECT Photonics is demonstrating its NarroWave enabled SFP+ modules. NarroWave is a new feature that allows customers to monitor and control remote SFP+ modules from the central office, without making any hardware or software changes in the field. NarroWave is agnostic of vendor equipment, data rate or the protocol of the in-band traffic. The host at the central office can access the remote digital diagnostics and monitoring by reading dedicated memory pages of the local SFP+, which are a mirror of the host device. This feature can also be used to send commands to a remote device, which enables use-cases such as automatic tuning and automatic power-balancing. This makes EFFECT’s SFP+ modules a powerful asset in the toolkit of any telecom provider looking to dynamically control and monitor its telecommunication network. Examples of NarroWave applications will be demonstrated live at EFFECT’s booth #6012.
Register here as our guest today for FREE pass to the exhibition and select “Exhibits Pass Plus” when registering. http://ofc2020.nvytes.co/ofc20/register/1230503.html
For more information please visit www.effectphotonics.com or contact sales@effectphotonics.com

EFFECT Photonics tapes out world’s first full photonic integration coherent PIC
Building on its Full Photonic Integration InP wafer scale platforms, EFFECT Photonics has taped out…
Building on its Full Photonic Integration InP wafer scale platforms, EFFECT Photonics has taped out the Manta chip: the world’s first fully integrated coherent PIC targeted at pluggable coherent transceivers for the edge and metro/access networks.
The Manta PIC fully integrates an ultra-narrow linewidth full band tunable laser, 64Gbaud coherent receiver, 64Gbaud coherent transmitter, wavelength locking and on-chip amplification for the transmit and receive paths. This gives unprecedented OSNR performance with power consumption lower than a stand-alone ITLA.
Tim Koene, VP Engineering at EFFECT Photonics, describes the benefits of the approach: “Full Photonic Integration means including all of the needed functions for coherent. In some approaches, the most costly functionalities, notably the laser, amplification and wavelength locking, are not integrated, and this creates optical loss, higher cost and higher assembly complexity. Truly integrating everything allows us to overcome those hurdles and create a high-performance, low-power consumption, low-cost solution for coherent.”
EFFECT Photonics will build small form-factor coherent pluggables optimised for industrial temperature operation. They will be deployed in next generation access networks and be able to provide turnkey coherent transmission over 120km of unamplified links.
James Regan, CEO at EFFECT Photonics, comments on the achievement: “Being able to deliver this single-chip solution in the same industrial-temperature specification, non-hermetic platform, with which we are shipping our tunable SFP+ targeting 5G wireless connectivity, is a game changer. It enables us to execute on our strategy and take the benefits of coherent technology closer than has been possible before to the end user in high-volume applications.”
The Manta PIC is fabricated on EFFECT Photonics’ 3″ InP platform and will be ported to 4″ fabrication later this year. It is set to drive a revolution in cost optimisation for the next generation of coherent networks.
-End-
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
For further information please contact sales@effectphotonics.com

EFFECT Photonics launches its new NarroWave – enabled tunable SFP+ modules
EFFECT Photonics announces the 2020 planned market launch of its new NarroWave – enabled SFP+…
EFFECT Photonics announces the 2020 planned market launch of its new NarroWave – enabled SFP+ modules for plug-and-play remote commissioning and control of telecoms networks. Not only will the tunable transceivers allow customers to commission an entire telecoms network from the central office and monitor critical parameters in the field, but they will do so with no loss in data capacity of the 10G SFP+ Transceivers . Additionally, no hardware upgrades for customers are required.
Dense wavelength division multiplexing (DWDM) has proved itself indispensable when it comes to adding capacity to existing networks. Tunability increases that flexibility and simplicity of use even further and reduces operating costs. EFFECT Photonics’ SFP+ transceivers combine tunable DWDM capability in a photonics System-on-Chip integration, a unique combination that simplifies production and testing, and results in enhanced optical transmission and low-energy consumption.
As Director of Product Line Management Joost Verberk explains, “With all the optical components on a single die, you don’t lose any light as you would in with lasers, mirrors and prism connected through air (free space optics). This is a big advantage because generating the laser light requires energy. Our chips transmit light with high efficiency, or low-energy consumption. Basically, we get a lot of light out of the module for the electrons we put in.” That means tunable DWDM capability in a photonics System-on-Chip integration creates further reductions in operating costs and enhanced functionality, as well as performance relative to fixed-wavelength systems built in manual processes from individual components.
Additionally, EFFECT Photonics has created NarroWave technology that can be enabled on all EFFECT Photonics’ tunable SFP+ modules. Now customers will be able to remotely monitor and control their added capacity without diminishing it. According to Verberk, “NarroWave is a means for two of our SFP+ transceiver modules to talk to one another without interfering with our customers’ data channel by essentially creating an auxiliary channel between the two modules. You just plug it in. It can then be tuned manually from the central office or, with an ‘auto-tune’ feature, it can automatically find its way into the network and connect.”
Very few companies produce DWDM SFP+ modules, even fewer produce tunable ones, and EFFECT Photonics is the only one in Europe to do so. In that narrow field, EFFECT Photonics is already establishing itself as an important competitive option for telecoms providers. As the only company in the world that offers remote control and monitoring of System-on-Chip tunable SFP+ modules without loss of data capacity, EFFECT Photonics intends to lead the pack in the global 5G rollout and beyond, interconnecting humanity through fast, affordable, accessible, integrated communication technologies.

About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
For further information please contact: sales@effectphotonics.com

EFFECT Photonics receives investment from PhotonDelta
EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based…
EFFECT Photonics, a leading developer of high-performance dense wavelength division multiplexing (DWDM) optical components based on its optical System-on-Chip technology, today announced an investment from PhotonDelta.
EFFECT Photonics has secured €5M in funding to support its growing 5G and data centre business. The funds will be used to further accelerate product development and business scale-up, and thereby strengthens the integrated photonics ecosystem.
EFFECT Photonics’ CEO James Regan says the Internet of Things, virtual reality, and cloud services are growing in popularity every day, increasing the demand for the best service possible. “These applications all depend on the next generation of connectivity, and 5G mobile infrastructure relies on the backing of a world-class optical network enabled by EFFECT Photonics. We are extremely proud that PhotonDelta shows this confidence in us, and are certain that the investment will support our ongoing work to enable this next era of photonics connectivity.”
EFFECT Photonics CTO Boudewijn Docter adds: “At EFFECT Photonics, we integrate all of the optical functions into a single chip and combine it with low-cost, non-hermetic packaging and automatic tuning. Thus DWDM – the proven solution for core and metro networks – is now simple, cost-effective and scalable enough for 5G infrastructure rollouts around the world. This funding allows us to really push forward our next-generation products to bring even more powerful optical systems to the edges of the network”.
PhotonDelta CEO Ewit Roos explains: “EFFECT Photonics is a key player within our ecosystem, a frontrunner that develops and delivers complex integrated optical products in a high-volume global market that demands 5G connectivity now. To this end, we are thrilled to fund EFFECT Photonics in developing their products and scaling up their business. Their products are supported by many other companies in the field of photonic integration services and components. Thus, the business growth of EFFECT Photonics has a profound impact as it leverages the scale of activity and innovation of the entire supply chain of integrated photonics in the Netherlands.”
– Ends –
About EFFECT Photonics
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip technology. The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers. Headquartered in Eindhoven, The Netherlands, with additional R&D and manufacturing in South West UK, with sales partners worldwide. www.effectphotonics.com
For further information please contact us:
press@effectphotonics.com
+31 40 3041359
About PhotonDelta
PhotonDelta is a growing ecosystem in Europe that covers a network of companies and knowledge institutes that intensively co-operates for the last 25 years in the research, design, development and manufacturing of integrated photonics technologies and components. Mainly focused on the Netherlands, such a collective and long-standing effort has led us to acquire unique competences and assets in the domain of photonics integrated circuits (PICs). Integrated photonics is a key enabling technology to create scalable solutions for societal and technological challenges the world faces today. By working together within a mission-driven ecosystem, we innovate, reduce time-to-market and create economy of scale that benefits us all. PhotonDelta provides access, knowledge, business development and funding to our partners. Our goal is to further establish and grow the integrated photonics ecosystem by 2026. Funding is made possible by substantial financial contributions from our partners as a result of our ‘partnerconvenant PhotonDelta’ and the “RegioDeal Brainport Eindhoven”. www.photondelta.eu
For further information please contact:
Ewit Roos
info@photondelta.eu
+31 85 112 43 37

EFFECT Photonics New Company Logo
EFFECT Photonics, a leading developer of high performance DWDM optical components based on its optical…
EFFECT Photonics, a leading developer of high performance DWDM optical components based on its optical System-on-Chip, today announce the launch of the new company logo.
EFFECT Photonics has grown and developed and as a result of this we have evolved the logo to reflect our journey so far.
Our new evolved logo reflects the following core elements:
• We have retained the warm red and will continue to do so
• The bolder font for the EFFECT logo reflects the evolution and growth of the company
• The horizontal lines of the graphic below the ‘EFFECT’ logo has been simplified
• The fonts have been updated to make it legible for both screen and printing purposes
Over the coming months, EFFECT Photonics will be updating all of its marketing materials, both online and offline, to reflect the new logo. For those who require our new logo and usage guidelines, kindly send an email to: marketing@effectphotonics.com with ‘new logo request’ in the subject header.
About EFFECT Photonics
EFFECT Photonics, a leading developer of high performance DWDM optical components based on its optical System-on-Chip technology. Headquartered in Eindhoven, The Netherlands, the birthplace of Philips, with additional R&D and manufacturing in South West UK, with sales partners worldwide.

EFFECT Photonics’ expanded premises at Brixham, UK
Since 2015 EFFECT has also had a presence based in south west Devon UK, at…
Since 2015 EFFECT has also had a presence based in south west Devon UK, at the University of Plymouth Brixham Laboratory. EFFECT Photonics needed a specialised telecommunications product development and manufacturing facility based in Torbay, conveniently situated to provide access to the resources utilised by the well-established Hi-Tech cluster of companies and expertise locally based there, within the bay area.
Focus:
EFFECT Photonics develops and delivers highly integrated optical telecommunications products based on InP (Indium Phosphide) which is the material of choice for creating efficient laser light sources, waveguides, modulators, and photodiodes used in optical communication systems throughout the world.
Extensive development work, European funding, and collaboration with established telecom organisations has already been invested to develop and refine the processes needed for the integration of multiple optical functions within a single chip. Enabling low cost highly functionality products to support the next-generation of emerging communications systems and networks.
Products / Services
The key enabling technology for DWDM systems is full monolithic integration of all photonic components within a single chip and being able to produce these in volume with high yield at low cost. With this capability, EFFECT Photonics is addressing the need for low cost DWDM solutions driven by the soaring demand for high bandwidth connections between datacenters and back from mobile cell towers.
EFFECT Photonics multi-lane Photonics Integrated Circuit (PIC) solutions are photonic enablers for pluggable module product solutions supporting multi-lane distributed (MLD) photonic applications, with aggregate transmission speeds of 100Gbps. Utilising the CFPx and (Q)SFP pluggable form factors, these modules support DWDM applications which require high physically rack density, and 100Gbps transmission link requirements in excess of 80km without the need for advanced coding, or fibre dispersion management, reducing implementation cost and rapid of system commissioning.
About EFFECT Photonics:
EFFECT Photonics delivers highly integrated optical communications products based on its Dense Wavelength Division Multiplexing (DWDM) optical System-on-Chip (SoC) technology. As a spin out of the prestigious Technical University of Eindhoven, EFFECT Photonics takes a platform approach to integration using high-yielding building blocks within the wafer. Growing different quaternary alloys of Indium Phosphide on a single wafer means that all of the active and passive optical functions of a system can be created within a single chip, which is then combined.
For more information, please contact info@effectphotonics.com

EFFECT Photonics Join the Discussion at NGON & DCI World 2019
The journey to 5G & beyond How will 5G impact optical networks? What are the…
The journey to 5G & beyond
How will 5G impact optical networks? What are the big operational plays that carriers and operators will need to take to ensure their architecture is fully equipped for 5G? Hear about the technologies and strategies to equip your network.
NGON & DCI World 2019
Join us this 21-23 May at NGON & DCI World 2019, Nice France – the number one meeting place for the optical networks industry. Don’t miss three packed days of content from the world’s leading thinkers in the space. For more information on the agenda, please visit: https://tmt.knect365.com/next-generation-optical-networking/agenda/1
EFFECT Photonics Join the Panel discussions:
- Where: NGON & DCI World 2019, Nice France
- What: Track A – 5G Evolution & Network Transformation
- When: Thursday, 23 May 2019 12:05 – 12:45
- Speaker: James Regan – CEO EFFECT Photonics
- Topic: The Vendor Roadmap / What is the view from the solution and technology providers on 5G?
In this unique format, EFFECT Photonics lines up with some of the key players on the vendor side facing a unique line-up of question masters, played by carriers. Hear the panel answer questions and see EFFECT’s views on 5G and where the optical networking industry can support.
1. How do we see 5G – what are the opportunities & challenges that we see?
2. What do we predict to be the key economic benefits?
3. What are the preparations we would advise to undertake to prepare for 5G?
4. What does wireless means for optical networks?
Interesting in attending our session? Please register here: http://bit.ly/2YfWh4T or contact info@effectphotonics.com

EFFECT Photonics is exhibiting at OFC 2019 (5 – 7 March 2019)
Bringing affordable DWDM to the edges of the network From March 5 to March 7…
Bringing affordable DWDM to the edges of the network
From March 5 to March 7 2019, EFFECT Photonics will be exhibiting at the OFC (Optical Networking and Communication Conference & Exhibition) in San Diego, California, USA. OFC is the largest optical communications conference in the world. Representing a range of products, from optical components and devices to systems, test equipment, software and specialty fiber, OFC represents the entire supply chain and provides the premier marketplace where the industry learns, connects, networks and closes deals.
Interested in what EFFECT Photonics is working on right now? We are exhibiting at booth #2647 and will be showing:
Narrowband Tunable SFP+ Transceiver for Fronthaul (LIVE DEMO)
Based on our ‘Optical System-on-Chip’ technology EFFECT Photonics is launching their first product into the market. Our Narrowband Tunable SFP+ can be used for Mobile Fronthaul applications. It supports Industrial Temperature operation, allowing customers to use in it in outdoor environments. With a reach of up to 40km, it can be used in virtually any Fronthaul network. This tunable solution brings flexible and affordable DWDM to the edges of the network.
Autonomously Tunable SFP+ Transceiver
Network traffic at the edge of the network will grow exponentially over the next few years. As operators strive to configure services and deploy applications dynamically, robust and operationally simple fibre networks become critical. Modules that autonomously tune to the required wavelength are an essential component of these low-cost access networks. EFFECT Photonics technology allow operators to rapidly and economically scale their optical networks.
For more information, please contact info@effectphotonics.com

EFFECT Photonics completes its Series-B funding to accelerate production ramp and to fund the next wave of technology development
EFFECT Photonics, a leading developer of high performance DWDM optical components based on its optical…
EFFECT Photonics, a leading developer of high performance DWDM optical components based on its optical System-on-Chip, today announced the completion of its series-B funding round led by Innovation Industries.
The funding round accelerates the ramp of its tunable SFP production line and the development of future technologies. EFFECT Photonics addresses the need for low-cost, wavelength-tunable optical transceivers with industrial temperature specification to be deployed within the next generation 5G mobile infrastructure. The global market demand for optical transceivers is expected to grow to $12bn by 2023, from $6bn in 2017 (Lightcounting, 2018).
5G mobile or fifth-generation wireless communication will enable interconnectivity with many different devices such as:
– HD-streaming smartphones
– Driverless and intelligence assisted vehicles
– HD and ‘always on’ security cameras
– Augmented and Virtual Reality (A/VR)
This in turn will accelerate the adoption of the Internet of Things (IoT) interconnecting computing devices and machines without the need for human-to-human or human-to-computer interaction. The number of connected devices in 2017 was 20.35bn (worth over $1bn annually) and is expected to rise to 51.1bn connected devices by 2023 (Statista 2018).
James Regan, CEO at EFFECT Photonics commented, “We are experiencing now in photonics what we saw in the electronics integration revolution last century. There the birth of the Integrated Circuit enabled the mass deployment of powerful solutions. At EFFECT Photonics we integrate all of the optical functions into a single chip and combine it with low-cost, non-hermetic packaging and automatic tuning. Thus DWDM, the proven solution for core and metro networks, is now simple, cost-effective and scalable enough for 5G infrastructure rollouts around the world”.
Boudewijn Docter, CTO added, “This funding also allows us to really push forward with our next-generation technology programme to bring even more powerful optical systems to the edges of the network”.
Nard Sintenie, Partner at Innovation Industries commented, “We are delighted to be a part of EFFECT Photonics who are at the forefront of developing optical transceivers with its photonic integrated circuits targeted at high growth markets such as 5G and fuelling the adoption of IoT enabled devices”.
About Innovation Industries
Innovation Industries is an independent venture capital fund that combines company-building and venture investment under one roof. Innovation Industries uses a market-driven approach to create long-term value in high technology start-up and scale-up companies. Our partnerships with all Dutch technical universities (Eindhoven, Twente, Delft and Wageningen) and applied research institutes (TNO) provide us with unparalleled access to knowledge and technologies. Innovation Industries has currently invested in ventures which are active in the nano- and microtechnology, semiconductor, food and agrotechnology, and medical technology fields. For further information about the portfolio companies please visit: https://www.innovationindustries.com/companies.
The Innovation Industries Fund is supported by private and institutional investors such as PME and InnovFin Equity. InnovFin Equity with the financial backing of the European Union under Horizon 2020 Financial Instruments and the European Fund for Strategic Investments (EFSI) set up under the Investment Plan for Europe. The purpose of EFSI is to help support financing and implementing productive investments in the European Union and to ensure increased access to financing.
For further information please contact:
Nard Sintenie
ns@innovationindustries.com
+316 10 01 10 72
About EFFECT Photonics
EFFECT Photonics, a leading developer of high performance DWDM optical components based on its optical System-on-Chip technology. Headquartered in Eindhoven, The Netherlands, the birthplace of Philips, with additional R&D and manufacturing in South West UK, with sales partners worldwide.
For further information please contact:
press@effectphotonics.com

EFFECT Features in Top 10 Dutch Breakthrough Technologies
Is photonics the answer to Moore’s Law? With our growing need for data and the…
Is photonics the answer to Moore’s Law? With our growing need for data and the transition to a 5G network, electronic chips may not be able to cut it anymore. Photons (light) can carry more data than electrons, are faster and can reduce the energy consumption in data traffic. Photonics is, therefore, a key enabling technology in this era of digitalization.
The Netherlands is positioned at the forefront of these developments and has a rich history in this field. Dating back to the 60’s Phillips developed optical fiber-technology. It was used in the telecommunications industry and also in the development of CDs, DVDs, and Blu ray. In July 2018 the Dutch government understand the future of photonics and announced an investment of 224 million euros in the development of the technology.
Ton Backx from the Institute of Photonic Integration is positive about this next step into Photonics: “This technology is going to change the world and solve some of the grand challenges we are facing. This technology will enable precision robots, medical sensors, optical variations on ultrasound, autonomous driving, smart cities and more. All these technologies will be based on the fundamentals of photonics.”
New startups in the Netherlands are forming to move this technology forward, specifically in the field of integrated photonic chips. Lionix and SMART Photonics are two examples: both foundries that allow other companies to build made to measure photonic chips. SMART Photonics in September 2018 raised €6 million and turned €4.5 million in loans into shares. This major investment will fund improving their production process whilst giving them a foundation for their next step in building a full production plant.
EFFECT photonics a spinout from TU Eindhoven also secured series A funding in 2018 (amount undisclosed). The funding will bring its Optical System-on-Chip technology to market to meet the soaring demand for bandwidth in cell towers and between datacentres. EFFECT Photonics develops and delivers highly integrated optical components based on InP (Indium Phosphide). Using EFFECT Photonics’ System-on-Chip Technology, port density can be increased by over 6-times and operational expenses reduced by 40% when compared with existing approaches.
The world is paying attention to the Photonics developments happening in the Netherlands. This year Synopsys, the world’s 15th largest software company acquired the Enschede based PhoeniX Software for an undisclosed amount. PhoeniX is a global supplier of photonic chip design solutions and acts as a proof point for the level of Photonics innovation happening in the Netherlands.
Further information can be found here.
Courtesy of Start Up Delta, and Medium.com.

EFFECT Photonics develops auto wavelength tuning for efficient DWDM network deployment
Following on from announcing the narrow tunable Dense Wavelength Division Multiplexing (DWDM) SFP+ optical transceiver…
Following on from announcing the narrow tunable Dense Wavelength Division Multiplexing (DWDM) SFP+ optical transceiver using their optical ‘System-on-Chip’ PIC technology, EFFECT Photonics are demonstrating their auto wavelength tuning feature at ECOC 2018 (Rome) in their private customer suite.
The EFFECT Photonics’ DWDM optical transceiver commences a sequence of wavelength tuning to establish a link with a transceiver at the opposite end of the link. This functionality is host-independent as the protocol is implemented within the optical transceiver.
Auto wavelength tuning simplifies network provisioning and deployment, which is especially useful for large-scale roll-outs of existing and next-generation mobile networks. It also significantly reduces the operational expenditure during the deployment of remote PHY network infrastructure.
The development of auto wavelength tuning is a result of customer feedback and the need to streamline the deployment and provisioning of new network infrastructure using tunable technology. This additional feature is also useful for system diagnostics and optimizing the link performance for communications equipment located in different environments.
Features of the system include:
– Compatible with 50/100 GHz and flexible grid spaced networks
– Suitable for 10Gbps and 25Gbps
– Distances of 40km or 80km
– Up to 40 bi-directional channels
To book a private meeting to see EFFECTs auto wavelength tuning feature at ECOC 2018 (Rome) from 25-26 September 2018, send an email to: meeting@effectphotonics.com
– Ends –
Further information:
Email: press@effectphotonics.com

EFFECT Photonics today enters into an agreement with Skylane Optics to supply narrow-tunable optical transceivers to Telecom operators in Europe, North and South America
Days after EFFECT Photonics announces the sampling of its low-cost narrow-band tunable DWDM SFP+ optical…
Days after EFFECT Photonics announces the sampling of its low-cost narrow-band tunable DWDM SFP+ optical transceivers for Next Generation Mobile Networks, it enters into an agreement with Skylane Optics to supply lineside optical DWDM tunable SFP+ optical transceivers to Telecom operators across Europe, North and South America.
Leveraging its optical System-on-Chip technology by using its high performance photonic integration platform, EFFECT Photonics offers a narrow-band tunable DWDM SFP+ optical transceiver designed for Telecom lineside applications. The costs associated with using EFFECT Photonics narrow-band tunable optical transceiver enables a reduction in sparing and provisioning costs by over 90%.
Skylane CEO, Philippe Bolle commented, “EFFECT Photonics’ narrow-band tunable optical transceiver addresses a need for Telecom operators to reduce their sparing and provisioning costs. In addition it solves the lack of availability of 10G DWDM fixed wavelength EML optical transceivers.”
VP Sales and Marketing, Robert Hughes commented, “We are extremely excited to be working with Skylane Optics to support them with this opportunity.”
Recently voted winner of the PIC International award for Advances in Photonic Integration, is combining the performance and tunability of indium phosphide with the cost point of full optical integration to deliver transceiver solutions to industry standard module formats which provide savings in operational costs and Capex.
EFFECT Photonics is exhibiting at ECOC 2017 (stand #549) which takes place in Gothenburg, Sweden, between 18-20 September 2017, and will be running a demo of its optical SoC technology.
-Ends –
Further information:
Email: press@effectphotonics.com
See us at ECOC 2017 stand #549

EFFECT Photonics announces sampling of its low-cost narrow-band tunable DWDM SFP+ optical transceivers, for Next Generation Mobile Networks
EFFECT Photonics announces sampling of its narrow-band tunable DWDM optical transceivers targeted at Next Generation…
EFFECT Photonics announces sampling of its narrow-band tunable DWDM optical transceivers targeted at Next Generation Mobile Networks.
As the capacity needed in cell towers soars with the latest Cloud RAN architectures, Dense Wavelength Division Multiplexing is required, delivering 40 or even 80 wavelengths on the fiber. This brings challenges in operational complexity to manage this many part codes from supply chain and deployment to the cell towers. Tunable wavelength lasers can solve this, but traditional full-band tunable modules are too expensive for this application.
Leveraging its optical System-on-Chip technology with advanced photonic integration and low-cost packaging, EFFECT Photonics provides an optimized solution dramatically reducing the number of part-codes at a cost point which meets the needs of Mobile networks.
EFFECT Photonics combines many optical functions within its PIC platform including, tunable lasers, MZI modulators, waveguides, SOAs, photodetectors, along with integrated wavelength locker to simplify the manufacturing process through integration. This coupled with EFFECT’s low-cost packaging enables the ability to scale in volume cost effectively.
CEO James Regan commented, “We are addressing the need for low cost tunability at the edges of the network by integrating the optical functions and simplifying packaging. This approach enables us to support our customers by reducing inventory and sparing costs by more than 90%.”
Recently voted winner of the PIC International award for Advances in Photonic Integration, is combining the performance and tunability of indium phosphide with the cost point of full optical integration to deliver transceiver solutions to industry standard module formats which provide savings in operational costs and Capex to Data Centre operators.
EFFECT Photonics will be exhibiting at ECOC 2017 (stand #549) which takes place in Gothenburg, Sweden, between 18-20 September 2017, and will be running a demo of its optical SoC technology.
-Ends –
Further information:
Email: press@effectphotonics.com
See us at ECOC 2017 stand #549

EFFECT Photonics wins Herald Express Business Award for `Most Innovative`
Over 300 people gathered together last Friday in South Devon for the award ceremony hosted…
Over 300 people gathered together last Friday in South Devon for the award ceremony hosted by the Herald Express. The purpose of the evening: Celebrating South Devon’s local businesses and, in particular, to reward those businesses and individuals who are helping to push the area forward, both culturally, economically and socially.
EFFECT Photonics entered the competition, hoping to win the award for ‘Most Innovative’. This award was created for businesses that established ground-breaking methods for developing new products or services. Over the past months, judges have been considering all aspects of the innovations process, from research to launch activity and more.
We are pleased to announce that EFFECT Photonics won the award for ‘Most Innovative’!
Paul Rosser, VP operations, said: “We’re hugely privileged to be part of the high-tech background in this wonderful location and we’re keen to grow in the Bay. This award is going to be a great help in promoting the company and recruiting.”
We would like to thank the organisation of Herald Express Business Awards 2017 for the recognition and the wonderful prize!

EFFECT Photonics announces new optical System-on-Chip (SoC) bringing low-cost tunability to Data Centre Interconnects and Metro
EFFECT Photonics announces a new, full band tunable optical System-on-Chip to meet the surging demand…
EFFECT Photonics announces a new, full band tunable optical System-on-Chip to meet the surging demand for inter-connecting Data Centres. This new optical SoC integrates:
- Extended 40nm C-band fully tunable laser
- Integrated on-chip wavelength measurement and control
- High speed, >32Gbaud Mach-Zehnder modulators
These optical features address the needs of advanced modulation formats and are optimised for the latest electronic ICs. By combining the optical functions in to a single chip, it enables full on-wafer characterisation and to use EFFECTs low cost non-hermetic packaging to reach the ever-decreasing cost points the market is looking for. This design block will also be combined into further, higher-functionality, multi-channel, optical SoCs.
EFFECT Photonics, recently voted winner of the PIC International award for Advances in Photonic Integration, is combining the performance and tunability of indium phosphide with the cost point of full optical integration to deliver transceiver solutions to industry standard module formats which provide savings in operational costs and Capex to Data Centre operators.
CTO, Boudewijn Docter commented, “We are extremely excited about our new optical SoC and EFFECT continues to develop new optical functions which the market is looking for. In addition, we have also combined our low-cost packaging technology to address the need to drive down the costs of optical transceiver modules for the Data Centre and Metro segments.”
EFFECT will be exhibiting at OFC 2017 (stand #1328) which takes place in Los Angeles, USA, between 21-23 March 2017, and running a separate demonstration of its optical SoC technology.
-Ends –
Further information:
Email: press@effectphotonics.com
See us at stand #1328 at OFC 2017

EFFECT Photonics joins the discussion at OFC 2017
During the Optical Networking and Communication Conference & Exhibition (OFC), a three-day series of Market Watch…
During the Optical Networking and Communication Conference & Exhibition (OFC), a three-day series of Market Watch panel discussions is organized. The discussions focus on the latest application topics and issues in the field of optical communications and feature esteemed speakers from industry, research and the investment community.
Photonic Integration Business Case – Reality Check.
James Regan will join the fifth discussion panel for a discussion called: Photonic Integration Business Case – Reality Check. The panel members have over 120 years of combined experience in the photonics business, so the discussion will get interesting, very quickly. The specialists aim to address the fundamental questions about the current key challenges in the field and the differences between InP, GaAs and Silicon technologies. Future market opportunities, along with topics such as packaging solutions will also be discussed.
What, where, when?
Interested to see what the experts have to say? Come see James and his industry peers in the LA Convention Center, Theater 1 on Thursday March 23. The discussion starts at 10:30 AM. For more information, check out the OFC panel V page.
Speakers:
James Regan; CEO, EFFECT Photonics B.V., Netherlands
Rick Dodd; SVP, Open Architecture, Ciena, USA
Martin Guy; Sr. Director, Packet Optical Platforms, Ciena, Canada
Frederick Kish Jr.; Sr. VP of the Optical Integrated Circuit Group, Infinera Corp, USA
Radha Nagarajan; CTO, Optical Interconnect, Inphi Corporation, USA
Tom Williams, Sr. Director of Marketing, Acacia Communications, USA

EFFECT Photonics is exhibiting at OFC 2017 (March 21-23)
In less than two weeks, EFFECT Photonics will be exhibiting at the Optical Networking and…
In less than two weeks, EFFECT Photonics will be exhibiting at the Optical Networking and Communication Conference & Exhibition in Los Angeles, US. OFC is the largest optical communications conference in the world. It’s a conference you cannot afford to miss! Think OFC is just about fibre optics? Think again! OFC has in-depth coverage of photonic integrated circuits, optical networking, free-space optical communications, quantum optics, and more.
Interested in what EFFECT Photonics is working on right now? You can find us at booth #1328!

EFFECT Photonics wins prestigious PIC Award!
Yesterday, CEO James Regan had the honour to receive an important award in the photonics…
Yesterday, CEO James Regan had the honour to receive an important award in the photonics business. EFFECT Photonics was selected as a finalist in the category “Advances in Integration” in January. After an exciting period of online voting, EFFECT Photonics was selected as the winner in this category!
The award was presented at the PIC Awards last night, during the PIC International 2017 networking dinner, which took place in Brussels, Belgium. The awards were initiated to recognise and highlight key industry achievements in advancing photonic integration through platform development, manufacturing, design, packaging and device characterisation.
We would like to thank the organisation of the PIC Awards for the wonderful prize and the recognition and of course thanks to everyone who took the time to vote for us!

EFFECT Photonics’ CEO James Regan to present at PIC International Conference
On March 7-8, the annual PIC International Conference takes place. The 2nd PIC International Conference will…
On March 7-8, the annual PIC International Conference takes place. The 2nd PIC International Conference will build on the success of its predecessors, with industry-leading insiders delivering more than 30 presentations spanning five sectors.
Together, these talks will detail breakthroughs in device technology; offer insights into the status and the evolution of compound semiconductor devices; and provide details of advances in tools and processes that will help to drive up fab yields and throughputs.
This year, EFFECT Photonics will be contributing to the PIC International Conference. On Tuesday March 7th, EFFECT Photonics CEO James Regan will present at the conference. His presentation will focus on Indium Phosphide as a platform for photonic integration. Come and join us for this interesting talk, it will start at 10.05 AM! For more information and the agenda for the PIC International Conference 2017, please visit the PIC International Conference website.

EFFECT Photonics is a finalist for the PIC Awards 2017!
We are proud to announce we’ve been chosen as a finalist for the PIC Awards…
We are proud to announce we’ve been chosen as a finalist for the PIC Awards 2017. The voting process is open until 21st February 2017. The winners will be announced on the 7th March at PIC International Conference in Brussels. We’d love you to vote for us! To do this and for more information visit the PIC Awards website.
Curious to see how we did? Check out the outcome right here!

Eindhoven is the place to be!
Read the article how Eindhoven takes position on the world ranking for expats. Learn more about Eindhoven!
Read the article how Eindhoven takes position on the world ranking for expats.
Learn more about Eindhoven!

EFFECT Photonics demonstrates 500Gbps PAM-4 capable TOSA, targeted at DCI and Metro Access Markets
Only 6 months after the successful launch of its 100Gbps DWDM transceiver product family in…
Only 6 months after the successful launch of its 100Gbps DWDM transceiver product family in March 2016, EFFECT Photonics is now demonstrating the ability to achieve 500Gbps using PAM-4 (4-level Pulse Amplitude Modulation) up to 75km, with its Optical ‘System-on-Chip’ photonic integration technology. This is the result of ongoing collaboration with the Technical University of Eindhoven, with further developments in the pipeline.
With Internet traffic expected to grow at an annual rate of 22-25% until 2020, the majority of this growth is coming from interconnecting Data Centres and in the Metro-Access segments. The need to reduce cost, power, and size continues to be a major driver of product innovation.
EFFECT Photonics is addressing this need with its Optical ‘System-on-Chip’ photonic integration platform by combining all of the optical functions into a single chip, and packaging this with its own low-cost ‘gold-box free’ packaging technology. The optical functions include: multiple DBR lasers, low-voltage drive MZ modulators, AWG, and wavelength monitoring, all within the single chip.
The powerful combination of EFFECT’s Optical ‘System-on-Chip’ photonic integration platform, unique low-cost packaging, and PAM-4 ticks all the boxes, reducing cost, power, and the physical size of the module – all this without the need for more expensive long-haul coherent optical transceivers.
VP Sales and Marketing, Robert Hughes commented “We knew very early on that combining many optical functions into a single ‘System-on-Chip’ offered a real alternative in the industry. This integration together with our novel packaging technology allows us to differentiate ourselves in the DCI and Metro-Access part of the network.”
EFFECT will be at demonstrating its 500Gbps PAM-4 capable TOSA at ECOC 2016, which takes place in Dusseldorf, Germany, between 19-21 September 2016.
-Ends –
Further information:
Email: press@effectphotonics.com
See us at stand #625 at ECOC 2016

Europe leads in the coming ‘light on a chip’ revolution
Interesting article in Venturebeat by Bert-Jan Woertman on how Europe and especially The Netherlands is…
Interesting article in Venturebeat by Bert-Jan Woertman on how Europe and especially The Netherlands is leading the way in the advancement of photonic technology.

EFFECT Photonics’ first optical ‘System-on-Chip’ technology launches in a new market, forecasted to grow to €30bn by 2025
Internet Service Providers around the world are facing the increasing challenges of delivering more services…
Internet Service Providers around the world are facing the increasing challenges of delivering more services to their data-hungry customers at a faster speed and a lower cost. Dutch High-Tech company launches its photonic integration technology targeted at mobile networks and Data Centers to address this growing demand, fueled by exceptional market growth at a rate of 58% CAGR for Data Centre interconnects and 45% for mobile.
Eindhoven, 18 April 2016. Eindhoven University spin-out, EFFECT Photonics, has recently launched and is sampling its first product family based on its optical ‘System-on-Chip’ photonic integration technology. The successful launch took place in March at a leading global industry trade show, OFC, in Anaheim, USA and generated strong interest with customers, analysts and trade media.
With the existing internet infrastructure unable to support the end-user demand, EFFECT’s photonic integration technology will address the increasing need for optical fiber bandwidth at low cost. With this revolutionary technology, an entire optical system can be integrated into a single chip, the size of a grain of rice, and manufactured cost effectively into a module that fits into the palm of your hand. Another advantage of this technology is its energy efficiency over existing solutions. This significantly reduces energy consumption, contributing to the overall sustainability of the Internet.
EFFECT’s optical ‘System-on-Chip’ technology will extend the edges of the Internet to help deliver high speed broadband to users at home, in the office, and on the move by improving broadband connection speeds and from mobile cell towers into the core of the Internet. The opportunity in this market is forecasted to grow to €30 billion by 2025.
EFFECT’s technology is integrated into a module which can handle many simultaneous data connections, greatly reducing the cost, physical space and power needed per connection. This technology makes it very attractive for Internet Service Providers and will ultimately benefit end-users. EFFECT’s products also support industry standard equipment, which means they can be used in existing and future communication systems.
CTO and founder, Boudewijn Docter commented “The last years have been very exciting; building our company from scratch, forming a great team, raising funds and making the technology ready for mass production. It’s a great adventure and recognizing the positive impact this will have on end-users around the world, makes it even more rewarding!”
Further information:
Email: press@effectphotonics.com

EFFECT Photonics’ CEO Regan to present optical ‘System-on-Chip’ technology at OFC
If you can’t make it, come and visit us at Booth 2833. #OFC2016
If you can’t make it, come and visit us at Booth 2833. #OFC2016

EFFECT Photonics launches first optical ‘System-on-Chip’ product family
Photonic integration start-up, EFFECT Photonics is launching its first product family based on its optical…
Photonic integration start-up, EFFECT Photonics is launching its first product family based on its optical ‘System-on-Chip’ technology platform which integrates all the active and passive components of a DWDM system within a single chip, without traditional gold box packaging.
EFFECT Photonics’ proposition addresses the soaring demand for affordable bandwidth between Data Centres and back from mobile cell towers by bringing Dense Wavelength Division Multiplexing technology to the edges of the network. By using the high integration ‘System-on-Chip’ Technology, port density can be increased by over 6-times and operational expenses reduced by 40% when compared with existing approaches.
The product family includes transceivers for transmission of 100Gbps over 80km at lowest cost and power, together with high density solutions containing many wavelengths for emerging WDM Access markets in fronthaul, backhaul and NGPON2. Industry standard sockets are supported including CFP and CFP2, meaning the products can be used in existing and future systems.
James Regan, CEO commented “We could see a bandwidth crunch coming at the edges of the network and knew that DWDM could be the answer, but it had to be done differently, so we developed a holistic solution from the ground up. We have completely re-thought how to tackle the issues of cost, power and density. As well as integrating many optical functions into a single chip, we have reduced the cost and complexity of our packaging resulting in a commercially viable solution. Regan added “We’re now at the sampling stage which is a very exciting time for us, after all the hard work we’ve put in in the past years”.
Andrew Schmitt, founder and analyst at Cignal Al, said “100 Gbps over 40km to 80km is a significant market opportunity that has no cost effective solution today. This is the next battleground for 100G solutions.”
EFFECT Photonics will be showcasing its new product family at the forthcoming industry event OFC, booth no 2833, taking place in Anaheim, CA, between 20-24 March 2016.

EFFECT Photonics closes Series-A funding
Dutch company enables photonic integration technology for mobile networks and datacentres and revolutionizes density, cost,…
Dutch company enables photonic integration technology for mobile networks and datacentres and revolutionizes density, cost, and power.
EFFECT Photonics today announced that it has closed its Series-A funding to bring its Optical System-on-Chip technology to market to meet the soaring demand for bandwidth in cell towers and between datacentres. The first close of the investment round was led by investment company b-to-v Partners, and included the Brabant Development Agency (BOM) and Optidob. EFFECT Photonics develops and delivers highly integrated optical components based on InP (Indium Phosphide) which is the material of choice for combining efficient laser light sources, waveguides, modulators, amplifiers, and photodiodes used in optical communication systems throughout the world. Using EFFECT Photonics’ System-on-Chip Technology, port density can be increased by over 6-times and operational expenses reduced by 40% when compared with existing approaches.
EFFECT Photonics is a spin out from the prestigious Technical University of Eindhoven (TU/e) which has been at the forefront of European photonic integration research. EFFECT Photonics, the recent winner of the Invest in Photonics Best Company award combines a team of integration technology innovators and experienced photonics industry veterans with backgrounds in Bookham, Nortel Components, JDSU and Agility.
James Regan, CEO, commented: “Dramatically increasing consumer demand for mobile video is driving a wave of data through cell towers and between datacentres that is expected to rise ten times over the next four years, creating a capacity crunch that only Dense Wave Division Multiplexing (DWDM) can solve. With our DWDM Optical System-on-Chip and advanced packaging technologies we enable the cost structure network providers need in a competitive market environment.”
Dr. Christian Reitberger, joining the board of the company on behalf of b-to-v Partners, commented: “We are excited to work with the EFFECT Photonics team to deliver on the vision of highly cost effective photonic integration, combining the intellectual capital of Eindhoven and the South West UK know-how clusters. The photonic manufacturing ecosystem has finally evolved to make capital-light photonic hardware companies a reality.”
Miriam Dragstra, Managing Director of BOM Capital added: “We are very pleased to have the opportunity to support EFFECT Photonics as a high-potential photonics start-up in our region, which has established itself as world-leading in the area of Integrated Photonics. Our investment will contribute to increasing that critical mass and its spin-off to the community further.”
For more information about EFFECT Photonics, visit: www.effectphotonics.com.
Source: EFFECT Photonics.
About EFFECT Photonics
EFFECT Photonics B.V. is spin out from the Technical University of Eindhoven (TU/e) and is a leader in the in the design and development of optical components using multichannel Photonic Integrated Circuits (PICs) in Indium Phosphide for mobile networks and datacentres. Headquartered in Eindhoven, The Netherlands, the birthplace of Philips, with additional R&D in South West UK and sales partners worldwide. For additional information, visit: www.effectphotonics.com.
Media contact
Email: press@effectphotonics.com
About b-to-v Partners
Based in St. Gallen, Switzerland, and Berlin, Germany, b-to-v is one of the leading networks of private investors in Europe. The company also acts as an independent investor and invests in start-ups, mid-size companies and special investment opportunities in the areas of Internet&Mobile, Life Sciences and Clean Technologies. b-to-v’s investment philosophy is based on creating sustainable added value for its portfolio companies while leveraging the industry expertise and entrepreneurial know-how stemming from the b-to-v’s network of private investors.
Media contact
Lennart Meyer
HOSCHKE & CONSORTEN Public Relations GmbH
Tel: +49 40 36 90 50-32
E-Mail: l.meyer@hoschke.de
About BOM
The Brabant Development Agency (BOM) promotes business development in a number of ways, with a particular focus on innovative companies and cross-industry initiatives that give the Brabant economy a lasting and competitive edge in a rapidly globalizing world and place the region among the top in Europe in terms of knowledge and innovation. BOM employs themed funds to invest venture capital in concepts with a promising future and encourages other public and private partners to come on board. In addition to venture capital and business development, BOM encourages knowledge-intensive and other foreign companies to establish themselves in Brabant. BOM also revitalizes existing economic potential, primarily by means of overhauling aging commercial sites.
